The machine is suitable to process very big size of plastic material, such as big diameter plastic pipe and plastic board and woDouble shaft plastic shredder character:
1. The machine is suitable to process very big size of plastic material, such as big diameter plastic pipe and plastic board and wood and tire and pressing plastic film which the single shaft plastic shredder can not process
2. The machine with big feeding mouth, it can put the big plastic product freely.
3. The rotary blade and cutting blade and blade edge with special design, it can get very high efficiency and high capacity
4. the machine is control by PLC system ,.the blade can rotated in opposite direction ,and also can close automatic if something unexpected happen , with very high safety service
5. The machine running slowly with low noise and low dusty
6. The blade material with special alloy steel made, with long life
Double shaft plastic shredder parameter:
Name | SNC2-600 | SNC2-600 | SNC2-800 | SNC2-800 | SNC2-1000 | SNC2-1200 | SNC2-1600 |
Power (kw | 11 | 15 | 22 | 37 | 2×30 | 2×30 | 2×37 |
Rotary blade | 12 | 12 | 16 | 16 | 20 | 24 | 22 |
Thickness of blademm | 50 | 50 | 50 | 50 | 50 | 50 | 70 |
Diameter of blademm | φ280 | φ280 | φ300 | φ300 | φ350 | φ400 | φ450 |
Qty of cutting edge | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
Crushing room dimensionmm | 600*550 | 600*550 | 800*600 | 800*600 | 1000*700 | 1200*800 | 1600*900 |
Capacitykg/h | 300~800 | 300~800 | 500~1500 | 500~1500 | 1000~2000 | 1500~2500 | 2000~3000 |
Dimension L*W*Hmm) | 3000*2000*2100 | 3000*2000*2100 | 3600*2000*2420 | 3600*2000*2420 | 3500*2000*2820 | 3800*2000*2820 | 4700*2000*3000 |
Weightkg | 2800 | 2900 | 4100 | 4300 | 6500 | 7000 | 10500 |
