Specifications
plastic film compacting agglomerating machine1.strong design of double-bearing
2.high performance blade
Plastic Film Agglomerator
1.good mixing effect
2.scientific design
3.large capacivity
4.easy operation and installation
PP/ PE film plastic agglomerator
capacity:100-800kg
type:100L-800
material: PVC, PE, PS, PP, PS
1. Features:
The plastic flakes densifier or agglomerator is used to granulate the thermal plastic films, PET fibres, whose thickness is less than 2 mm into small ganules & pellets directly. The soft PVC, LDPE, HDPE, PS, PP, foam PS, PET fibres and other thermoplastics are suitable for it.
2. Working Principle:
When the waste plastic is supplied into the chamber of such machine, it will be cut into smaller chips due to the crushing function of the rotating knife and fixed knife. During the crushing processing, the material that soaked up lots heat from the frictional movement of material being crushing and the wall of container will be going to become semi-plasticizing state. The particles will stick with each other due to the function of plasticization. Before it sticks each other completely, the cold water pre-prepared is sprayed into the material being crushed. The water will be evaporated off quickly and the surface temperature of material being crushed drop down quickly also. So the material being crushed will become small particles or granules. It is easy to recognize the particles by different size and can be colored by using of color agent being putted into the container during the crushing processing.
3. Main Technicial Parameter:
Model |
GHZ-300 |
GHZ-450 |
GHZ-600 |
Volume |
300L |
450L |
600L |
Effective capacity |
200L |
350L |
450L |
Rotating blade Qty |
2 |
2 |
2 |
Fixed blade Qty |
6 |
8 |
8 |
Rotatting speed |
950 rpm |
950 rpm |
950 rpm |
Motor power |
55kw/75kw |
90kw |
110kw |
Output |
250-300kg/h |
350kg/h |
500kg/h |
