Home > Manufacturing & Processing Machinery > Machine Tools > Milling Machine > High Output Plastic Milling Machine/miller Machine/milling Machinery
High Output Plastic Milling Machine/miller Machine/milling Machinery
US$ 5,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
sevenstars plastic milling machine
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Plastic Grinding Machine/plastic PulverizerUS$ 3,000 - 20,000MOQ: 1 Set -
High Quality Disc Plastic Pulverizer/plastic GrinderUS$ 2,000 - 20,000MOQ: 1 Set
-
PVC Pulverizer Mill MachineNegotiableMOQ: 1 Set
-
PVC Plastic Miller MachineNegotiableMOQ: 1 Set
-
PVC PE LDPE LLDPE Waste Plastic Milling MachineUS$ 8,000 - 12,000MOQ: 1 Set
Condition
New
Place of Origin
Jiangsu, China
Brand Name
sevenstars plastic milling machine
Model Number
BDX
Type
Vertical
CNC or Not
Normal
Voltage
380V 50HZ or customized
Power(W)
per different capapcity
Dimension(L*W*H)
2*2*3m plastic milling machine
Weight
500-800kg
Certification
CE ISO plastic milling machine
Warranty
1 year plastic milling machine
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
plastic milling machine1. Advanced desgin
2. Convenient installation
3. Low powder consumption
4. ISO 9001:2000
Plastic milling machine
Plastic milling machine
Performance characteristics
The automatic plastic grinding mill machine which has the advantages of high-yield and lower-power .this machine can be used for powder processing of polyethlene (PE),polyvinylchloride (pvc), polypropylene (pp),polystyrene (ps),ABS,nylon and other materials.
- the new disc design is used ,high-yield,strong resistance and the life of grinding disc is double the ordinary.
- the use of newly designed professional bearings ,and reached a high rotation rate ,at the same time using only one drive motor ,to ensure the efficient grinding crash,which greatly saves the time and operation of machinery and control engineering .
- installation and maintenance easy ,open the door to cover clean-up
- milling process of the whole seal,without dust leakage
- full automated ,automatic feeding ,the materials and sorting
- grinding gap adjustment is simple ,just use the plug-foot bolts and adjustments can be fine-tuning
- the host used the water and wind double cooling systerm ,rational design of smaller cross-section of the grinding chamber ,grinding is almost flat vertical surface.material entered the grinding chamberas soon as caught,groud,and then rapidly removed,which eliminates the grinding chamber of the surge in materials,heating materials to avoid decomposition,resulting in improved production .
main technical parameter for plastic milling machine
Model | Main motor power(kw) | Draft fan power (kw) | Vibration sieve power (kw) | Feeder power (kw ) | Output (kg/h) | Dimensions(mm) | Weight (kg) |
MF-500 | 37 | 5.5 | 0.75 | 0.75 | 180-300 | 1900*1700*3900 | 2200 |
photos for plastic milling machine
