Home > Manufacturing & Processing Machinery > Machine Tools > Grinding Machine > Plastic Grinding Machine/plastic Pulverizer
US$ 3,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Internal Grinding Machine
CNC or Not:
Normal
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Quality Disc Plastic Pulverizer/plastic GrinderUS$ 2,000 - 20,000MOQ: 1 Set -
PVC Pulverizer Mill MachineNegotiableMOQ: 1 Set
-
PVC Plastic Miller MachineNegotiableMOQ: 1 Set
-
PVC PE LDPE LLDPE Waste Plastic Milling MachineUS$ 8,000 - 12,000MOQ: 1 Set
-
Waste Plastic Material Pulverizer Miller Machine for PVC PP PE ABS PETNegotiableMOQ: 1 Set
Condition
New
Type
Internal Grinding Machine
CNC or Not
Normal
Max. Grinding Diameter
per different capacity plastic grinding machine
Max. Grinding Length
per different capacity
Place of Origin
Jiangsu, China
Brand Name
sevenstars plastic grinding machine
Model Number
BDX
Voltage
380V 50HZ or customized
Power(W)
37kw plastic grinding machine
Dimension(L*W*H)
2*2*3m
Weight
300-800T plastic grinding machine
Certification
CE ISO
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
plastic grinding machine1. Advanced desgin
2. Convenient installation
3. Low powder consumption
4. ISO 9001:2000
Plastic milling machine
Plastic milling machine
Performance characteristics
The automatic plastic grinding mill machine which has the advantages of high-yield and lower-power .this machine can be used for powder processing of polyethlene (PE),polyvinylchloride (pvc), polypropylene (pp),polystyrene (ps),ABS,nylon and other materials.
- the new disc design is used ,high-yield,strong resistance and the life of grinding disc is double the ordinary.
- the use of newly designed professional bearings ,and reached a high rotation rate ,at the same time using only one drive motor ,to ensure the efficient grinding crash,which greatly saves the time and operation of machinery and control engineering .
- installation and maintenance easy ,open the door to cover clean-up
- milling process of the whole seal,without dust leakage
- full automated ,automatic feeding ,the materials and sorting
- grinding gap adjustment is simple ,just use the plug-foot bolts and adjustments can be fine-tuning
- the host used the water and wind double cooling systerm ,rational design of smaller cross-section of the grinding chamber ,grinding is almost flat vertical surface.material entered the grinding chamberas soon as caught,groud,and then rapidly removed,which eliminates the grinding chamber of the surge in materials,heating materials to avoid decomposition,resulting in improved production .
main technical parameter for plastic milling machine
Model | Main motor power(kw) | Draft fan power (kw) | Vibration sieve power (kw) | Feeder power (kw ) | Output (kg/h) | Dimensions(mm) | Weight (kg) |
MF-500 | 37 | 5.5 | 0.75 | 0.75 | 180-300 | 1900*1700*3900 | 2200 |
photos for plastic milling machine
