pe Hdpe Plastic Drain Pipe Making Machine/hdpe Pipe Lines/pipe Extruding Machinery

pe Hdpe Plastic Drain Pipe Making Machine/hdpe Pipe Lines/pipe Extruding Machinery thumbnail-1
pe Hdpe Plastic Drain Pipe Making Machine/hdpe Pipe Lines/pipe Extruding Machinery photo-1
US$ 15,000 - 70,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Pipe
Plastic Processed:
PE
Contact Supplier Request Quote Chat Now
Zhangjiagang Horse Rider Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai pe hdpe plastic drain pipe making machine
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Pipe
Plastic Processed PE
Screw Design Single-screw
Automatic Grade automatic
Place of Origin Jiangsu, China
Brand Name Horse Rider
Model Number Horse Rider
Voltage 380V,50HZ,3P or According to your needs
Power(W) 37kw
Dimension(L*W*H) 20mx2.5mx2.2m
Weight 10T
Certification CE
After-sales Service Provided Engineers available to service machinery overseas



ppr pipe production line/electrical wire pipe making machine/hdpe pipe machinery

pe pipes extrusion line/pe pipe production line/pe pipe extrusion machine



pe ppr plastic pipe making machinery/plastic pipe making machine/plastics making machine pipe making machine

plastics making machine for ppr pipe making machinery /ppr pipes making machine

ppr pe pipe making machine/used machine & facility for  ppr pipes making machine

hdpe pe pipe extrusion line/pe pipes extrusion line/ pipe extruder machine/pe pipe extruding machine

plastic pipe extrusion line
pipe diameter:16mm-1800mm
Max. output:150-1500kg/h
extruder:high efficient single screw extrude

hdpe pipe making machine

hdpe pipe making machinery



pe pipe production line

pe pipe extrusion line

pe pipes extrusion line



hdpe pe pipe extrusion line/pe pipes extrusion line/ pipe extruder machine/pe pipe extruding machine

PE pipe extrusion line

A. The main extruder adopts PE high-efficiency screw, notched feeding cylinder and is equipped with strong water jacket cooler, which greatly improves its transmission capacity and guarantees high-efficiency extrusion.

B. The basket composite machine head adapted for PE processing not only guarantees extrusion stability at high speed, but also realizes minimum stress and highest pipe quality in low temperature.

C. The high-efficiency double-cavity vacuum sizing technology and spray cooling tank improves the rate of finished product and meets the need of high-speed production. D. Adopt multi-pedrial tractor to drive all pedrials through central motor to get synchronous height and guarantees pipe’s roundness.

E. The high-speed, precise designed cutting machine is low in noise. And it is also equipped with strong scrap attracting device to reduce the work of maintenance to the lowest degree.



Main Technical Paramber of   pe ppr plastic pipe making machiner

 MODEL

 Diameter(mm)

 Extruders

 Max.Output(kg/h)

 Toal Power(KW)

 YLPEG-110

 20-63

 YL-SJ60/33 YL-25/25

 120-220

 130

 YLPEG-150

 50-160

 YL-SJ60/33 YL-25/25

 120-220

 130

 YLPEG-250

 110-250

 YL-SJ75/33 YL-25/25

 280-350

 280

 YLPEG-450

 160-450

 YL-SJ90/33 YL-25/25

 350-500

 400

 YLPEG-630

 315-630

 YL-SJ120/33 YL-30/30

 550-980

 550

 YLPEG-800

 400-800

 YL-SJ150/33 YL-30/30

 800-1400

 750

 YLPEG-1600

 800-1600

 YL-SJ150/33 YL-30/30

 800-1400

 1200



More pictures about  pe ppr plastic pipe making machinery

 1.extruderpe hdpe plastic drain pipe making machine/hdpe pipe lines/pipe extruding machinery



-extruder

pe hdpe plastic drain pipe making machine/hdpe pipe lines/pipe extruding machinery

3.water cooling tank



pe hdpe plastic drain pipe making machine/hdpe pipe lines/pipe extruding machinery



4. haul-off machine



pe hdpe plastic drain pipe making machine/hdpe pipe lines/pipe extruding machinery



5. automatic pipe cutter

pe hdpe plastic drain pipe making machine/hdpe pipe lines/pipe extruding machinery





pe hdpe plastic drain pipe making machine/hdpe pipe lines/pipe extruding machinery

pe hdpe plastic drain pipe making machine/hdpe pipe lines/pipe extruding machinerype hdpe plastic drain pipe making machine/hdpe pipe lines/pipe extruding machinerype hdpe plastic drain pipe making machine/hdpe pipe lines/pipe extruding machinery
