Waste Plastic LDPE HDPE Nylon Bags Three Stage Water Ring Hot Cut Pellletizing Recycling Line With High Output Low Price

Waste Plastic LDPE HDPE Nylon Bags Three Stage Water Ring Hot Cut Pellletizing Recycling Line With High Output Low Price thumbnail-1
Waste Plastic LDPE HDPE Nylon Bags Three Stage Water Ring Hot Cut Pellletizing Recycling Line With High Output Low Price thumbnail-2
Waste Plastic LDPE HDPE Nylon Bags Three Stage Water Ring Hot Cut Pellletizing Recycling Line With High Output Low Price thumbnail-3
Waste Plastic LDPE HDPE Nylon Bags Three Stage Water Ring Hot Cut Pellletizing Recycling Line With High Output Low Price thumbnail-4
Waste Plastic LDPE HDPE Nylon Bags Three Stage Water Ring Hot Cut Pellletizing Recycling Line With High Output Low Price thumbnail-5
Waste Plastic LDPE HDPE Nylon Bags Three Stage Water Ring Hot Cut Pellletizing Recycling Line With High Output Low Price thumbnail-6
Waste Plastic LDPE HDPE Nylon Bags Three Stage Water Ring Hot Cut Pellletizing Recycling Line With High Output Low Price photo-1
Waste Plastic LDPE HDPE Nylon Bags Three Stage Water Ring Hot Cut Pellletizing Recycling Line With High Output Low Price photo-2
Waste Plastic LDPE HDPE Nylon Bags Three Stage Water Ring Hot Cut Pellletizing Recycling Line With High Output Low Price photo-3
Waste Plastic LDPE HDPE Nylon Bags Three Stage Water Ring Hot Cut Pellletizing Recycling Line With High Output Low Price photo-4
Waste Plastic LDPE HDPE Nylon Bags Three Stage Water Ring Hot Cut Pellletizing Recycling Line With High Output Low Price photo-5
Waste Plastic LDPE HDPE Nylon Bags Three Stage Water Ring Hot Cut Pellletizing Recycling Line With High Output Low Price photo-6
US$ 30,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Granules
Plastic Processed:
PE
Contact Supplier Request Quote Chat Now
Zhangjiagang Horse Rider Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Granules
Plastic Processed PE
Screw Design Single-screw
Automatic Grade Automatic
Place of Origin Jiangsu, China
Brand Name Horserider machinery
Model Number SJ, HRPM06
Voltage 380V 50HZ
Power(W) it depends on
Dimension(L*W*H) 8*2*2.5M
Weight 10 ton
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

Product Description

 waste plastic LDPE HDPE nylon bags three stage water ring hot cut pellletizing recycling line with high output low price

Feature and Function of pelletizing machine :

There noodle type and water ring type pelletizing line,recycling PP PE film bags,any other profile ,make them into pellets.

Process flow of  Plastic Three stages pelletizing machine :

Convey feeder→ Extruding machine SJ200/3300→ Die-head→Extruding machine SJ160/1780→Screen fliter with die head→Extruding machine SJ160/1780→Screen fliter with die head→ water-ring pelletizing machine→water tank→ Dewatering mchine→Storage silo



Model



(Screw Diameter)mm



 L/D



(Driving Motor)kw



(Output) kg/h

SJ-120/120

120/120

25

45kw/18.5kw

100-200kg/h

SJ-140/130

140/130

10/25

75kw/22kw

150-250kg/h

SJ-150/140

150/140

10/25

90kw/37kw

250-380kg/h

SJ-160-150

160/150

10/25

137kw/45kw

400-500kg/h

Pe PP Three stage film/woven bags pelletizing line

waste plastic LDPE HDPE nylon bags three stage water ring hot cut pellletizing recycling line with high output low pricewaste plastic LDPE HDPE nylon bags three stage water ring hot cut pellletizing recycling line with high output low pricewaste plastic LDPE HDPE nylon bags three stage water ring hot cut pellletizing recycling line with high output low pricewaste plastic LDPE HDPE nylon bags three stage water ring hot cut pellletizing recycling line with high output low pricewaste plastic LDPE HDPE nylon bags three stage water ring hot cut pellletizing recycling line with high output low pricewaste plastic LDPE HDPE nylon bags three stage water ring hot cut pellletizing recycling line with high output low pricewaste plastic LDPE HDPE nylon bags three stage water ring hot cut pellletizing recycling line with high output low pricewaste plastic LDPE HDPE nylon bags three stage water ring hot cut pellletizing recycling line with high output low price




 water ring type pelletizing machine
waste plastic LDPE HDPE nylon bags three stage water ring hot cut pellletizing recycling line with high output low price




 waste plastic LDPE HDPE nylon bags three stage water ring hot cut pellletizing recycling line with high output low price
