Help CenterNew Design Pvc Material Pelletizing Manufacturing Machine/soft and Rigid Pvc Pelletizing Production Cost
Related Products
-
High Quality and Low Cost New Pvc Material Pelletizing Machine/soft and Rigid Pvc Pelletizing Production Plant PriceUS$ 30,000 - 80,000MOQ: 1 Set -
High Output PP PE Film Granules Making MachineUS$ 30,000 - 50,000MOQ: 1 Set
-
High Output Rigid Soft Pvc Pelletizing MachineUS$ 30,000 - 50,000MOQ: 1 Set
-
High Output Side Force Feeder Plastic Material Pelletizing MachineryUS$ 30,000 - 50,000MOQ: 1 Set
-
High Output SJ120 Film Compacting Pelletizing LineUS$ 30,000 - 50,000MOQ: 1 Set
Model |
screw diameter (mm) |
L/D |
Capacity (kg/h) |
Main motor power(kw) |
Total power (kw) |
Line length (m) |
SJZ51 |
51/105 |
14.5:1 |
120 |
18.5 |
70 |
12 |
SJZ65 |
65/132 |
14.6:1 |
200 |
37 |
100 |
14 |
SJZ80 |
80/156 |
15.25:1 |
350 |
55 |
150 |
16 |
SJZ92 |
92/188 |
17.86:1 |
600 |
90 |
200 |
18 |
PVC PELLETIZING LINE
With different designs of screw, this machine can be applied to granulate the recycled material of rigid PVC, soft PVC and waste PVC. It can be stopless in the course of production.It used pneumatic conversion and strong-wind blowing. At the same time can adjust stainless steel storage container and can run at high speed for a long time while extrude stably.
Process flow:
Raw material+ additive → Mixing → Material feeding→ Conical twin screw extruder → Blowing hot-cutting mould → Cyclone separator → Vibrating screener → Blowing system → Storage hopper → Finished product packing
