PVC Mixer Machine / PVC Plastic Mixer Machine / Mixer Machine for PVC Powder Material
US$ 6,500 - 9,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Plastic Processing Mixer
Automatic Grade:
Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PE PP PIPE POWDER HIGH SPEED HEATING AND COOLING MIXER UNIT/PVC C PE PP PIPE POWDER HOT AND COLD MIXER UNITUS$ 5,000 - 10,000MOQ: 1 Set -
High Speed PVC Compounding Plastic Mixer Machine / High Speed PVC Power Formula Material Mixer MachineUS$ 6,500 - 9,000MOQ: 1 Set
-
PVC WPC WINDOW PROFILE POWDER HIGH SPEED HEATING AND COOLING MIXER UNIT/PVC WPC DOOR BOARD POWDER HOT AND COLD MIXER UNITUS$ 5,000 - 10,000MOQ: 1 Set
-
PVC OXYGEN PIPE HOSE POWDER HIGH SPEED HEATING AND COOLING MIXER UNIT/PVC OXYGEN HOSE PIPE DUST HOT AND COLD MIXER UNITUS$ 5,000 - 10,000MOQ: 1 Set
-
PVC GARDEN HOSE POWDER HIGH SPEED HEATING AND COOLING MIXER UNIT/PVC WATERING PIPE POWDER HOT AND COLD MIXER UNITUS$ 5,000 - 10,000MOQ: 1 Set
Condition
New
Application
Plastic Processing Mixer
Automatic Grade
Automatic
Production Capacity
200-1500kg/H
Brand Name
Zhangjiagang Horserider
Model Number
SRL
Voltage
380V 50HZ
Power(W)
40/55kw
Dimension(L*W*H)
2500*2100*3000 mm
Weight
3000kg
Certification
CE ISO SGS
Warranty
15 Months
After-sales Service Provided
Engineers available to service machinery overseas
pvc mixer machine
Product Description:
The pvc mixer machine is widely used for mixing, drying, and coloring for all kinds of plastic resin, especially for large PVC Pipe Profile production capacity. This unit is composed of heating and cooling mixers. Hot material from heating mixer is fed into cooling mixer for cooling to eliminate gas and avoid burning. The structure of cooling mixer is horizontal type with spiral-shape stirring blades, without dead corner and prompt discharging within short time.
SRL-Z300/600 Mixer for example:
| SRL-Z300/600 Hot and Cold Mixer | ||
| Introduction | ||
| SRL-Z series horizontal hot&cold mixer, is mainly suitable for all kinds of resin(such as PVC, PE,PP)modified PITF etc. And the mixing, disperseng coloured, drying etc. Technological process of allkinds of suxiliary packing, subsidiary material. And for ABS,PC drying seperating and waving before fished form process of engineering plastics. | ||
| Technical parameter | ||
| Name | Hot pot | Cold pot |
| Total volume(L) | 300 | 600 |
| Effective volume(L) | 200 | 360 |
| Vane rotating speed(Rpm) | 475/950/130 | |
| Motor and heating power(KW) | 40/55/11 Plastic Mixer, PVC Powder Mixer Machine,Plastic Powder Mixer Machine | |
| Water consumption t/h | 3.8 | |
| Mixing Capacity(Kg/h) | 250-500 | |
| Heating method | electricity heating/ auto friction | |
| Dimension(mm) | 4580×2240×2500 | |
| Discharging method | pneumatic/manual | pneumatic |
| Weight(T) | 3.8 | |
| Mixing time m/p. pot | 8-10 m/p | 6-8m/p |
| Main Structure | ||
| 1.It is used in mixing, drying, colouring and other industrial art. It is an ideal equipment for producing profiles&pipes. | ||
| 2.Two layer of wealing is adopted in the pot cover. Pot cover of cooling machine adopts arch cover.which can avoid deforming. | ||
| 3.It has features of fine construction, good performance. | ||
| 4.They have passed dynamic and static equilibrium test. | ||
