Plastic Milling Grinder Machine/PVC Pulverizer
- shanghai port
- T/T Credit Card
You May Like
-
EVA Pvc Scraps Grinding Mill Miller/soft pe pp Drain Pipe Powder Pulverizer Machine
-
ABS EVA PVC Profile Scrabs Grinding Mill Miller/pe pp Material Powder Pulverizer Cost
-
LDPE HDPE PVC Profile Scrabs Granules Grinder Machine Price/soft and Hard pe pp Drain Pipe Powder Pulverizer Machine
-
Waste Plastic Pvc Door Flour Granules Grinding Miller/waste Hard pe pp Pvc Pulverizer Recycling Machine
-
Waste Plastic Pvc Pipe Scrabs Granules Grinding Miller/waste Hard pe pp Pulverizer Machine Price
-
Waste Plastic Pvc Scraps Granules Grinding Miller/waste Hard pe pp Window and Door Material Powder Pulverizer Machine
Product Details
| Place of Origin | Jiangsu, China | Brand Name | HorsiRider | |
| Model Number | MF | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
High Speed Plastic Miller / Grinder
Performance characteristics
The SMF series automatic plastic grinding mill is disc-type plastic grinding mill series,which has the advantages of high-yield and low-power.This machine can be used for powder processing of PE,PVC,PP,PS,ABS,nylon and other materiels.
1),The new disc design is used,high-yield,strong resistance and the life if this grinfding disc is double the ordinary.
2),The use of newly designed professional bearings,and reached a high rotation rate.At the same time using only one drive motor,to ensure the efficent grinding crash,which greatly saves the time and operation of machinery and control engerneering.
3),Installation and maintenance is easy,open the door to cover clean-up.
4),Milling process of the whole seal,without dust leakage.
5),Full automatic,auto matic feeding,the materials and sorting.
6),Gringding gap adjustment is simple,just use the plug-foot bolts and adjustments can be fine
tuning.
7),The host used the water and wind double cooling system,Rational design of smaller cross-section of the gringding chamber,grinding is almost flat vertical surface.Material entered the grinding chamberas soon as caught,groud,and then rapidly removed,which eliminates the grinding chamber of the surge in materials,heating materials to aviod decomposition,resulting in improved production.
8),For the PP and EVA/PET material,we have special design .
The Parameter
No | Item | SMF-400 | SMF-500 | SMF-600 |
1 | Main motor power | 30KW | 37KW | 45kw |
2 | Capacity (PVC 30-80mesh) | 50-120kg/h | 60-220kg/h | 280-380kg/h |
3 | Material of conveying pipe | Stainless steel | Stainless steel | Stainless steel |
4 | Total weight(kg) | 1000 | 1200 | 1800 |
The Equipment
