New type high output PVC Single Wall Wire Conduit Pipe Machine / single wall corrugated pipe extrusion line/electrical conduit pipe production line
Feature of PE single wall corrugated pipe extrusion line
This series single wall wire conduit pipe extrusion line can be used to produce corrugated pipes of PVC, PE, PP, EVA continuously, as well as PA corrugated pipes. Plastic single-wall corrugated pipes have features of high temperature resistance, resistant to corrosion and abrasion, high intensity, good flexibility, etc.
Use of PVC single wall wire conduit corrugated pipe
The single wall corrugated pipe are widely used in fields of auto wire, electric thread-passing pipes, circuit of machine tool, protective pipes of lamps and lanterns wire, tubes of air conditioner and washing machine, etc.
Single-wall corrugated pipe machine developed by our company adopts gears to run modules and templates so as to realize water circulating cooling and air cooling of the products, which ensures high-speed molding, even corrugation, smooth inner and outer pipe wall. These corrugated pipes are especially used in wires conduit pipe.
Part parameter of PVC Single Wall Wire Conduit Pipe Machine
Item | Parameter |
Extruder | SJ45 single screw extruder |
Pair of Mold Block | 60 |
Pipe State | Single wall corrugated pipe |
pipe diameter | 12-63mm |
Drawing Speed | 3~10m/min |
Mold Block Cooling Mode | Wind cooling |
Pipe Cooling Mode | Wind cooling |
Wind Cooling Power | 0.5×2KW |
Main Machine Power | 15-18.5KW |
Power of Auxiliary Machine | 2.2KW |
Weight | 2500kg |
Dimension | 7500mm×1600mm×1700mm(L×W×H) |
More model not list,please contact us for detailed information.
We are the manufacturer sepcialized in the field for many years.
Welcome to visit our factory at any time!
Reference photos of PVC Single Wall Wire Conduit Pipe Machine
(all photos and parameter of PE single wall corrugated pipe extrusion line only for reference)
