Specifications
New Plastic Agglomeration Machine1.High speed
2.high performance blade
3.temperature control
4.Output:50-800kg/h
New type high speed plastic film granulator / PE film granulating machine / PE film pelletizer with low power consumption plastic film pelletizer Plastic Film Agglomerator Plastic Agglomeration Machine
This agglomerator is mainly used for cutting and recycling thermoplastic film, soft
polyvinyl chlorid (PVC) waste chemical belt etc, such as garbage bags, carry
bags and milk pouches
It is for for augmentation of the bulk density of the LDPE, HDPE , PP , BOPP, PET film & bags flakes.
Features of Plastic Agglomeration Machine
- strong design of double-bearing for holding the main shaft
- high performance blades
- temperature control
- water flushing automatically
- motor power from 18.5kw to 132kw
- processing capacity from 50kg/h to 500kg/h
Main parameters of Plastic Agglomeration Machine
HRPA |
1600 |
1000 |
750 |
550 |
400 |
300 |
100 |
Tank volume Liter |
1600 |
1000 |
750 |
550 |
450 |
300 |
150 |
|
Working volume Liter |
960 |
600 |
450 |
330 |
270 |
180 |
90 |
Capacity Kg/h |
600-800 |
500-600 |
300-400 |
200-300 |
150-200 |
80~120 |
40~80 |
Motor power Kw |
132 |
110 |
90 |
75 |
55 |
37 |
18.5 |
Rotating blades speed r/min |
900 |
900 |
990 |
990 |
990 |
990 |
910 |
Rotating blades quantity |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
Stationary blades quantity |
7 |
6 |
4 |
4 |
4 |
4 |
4 |
Feeding gate size mm |
φ300 |
φ300 |
φ250 |
φ250 |
φ250 |
φ250 |
φ150 |
Discharging gate size mm |
280×250 |
280×250 |
200×200 |
200×200 |
200×150 |
200×150 |
150×150 |
Discharging model |
Pneumatic |
Pneumatic |
Pneumatic |
Pneumatic |
Pneumatic |
Pneumatic |
Pneumatic |
Water inlet |
1” |
1” |
1” |
1” |
1” |
1” |
1” |
|
Machine dimension L×W×H(m) |
2.7*2.2*2.6 |
2.7*1.8*2.4 |
2.2*1.5*2.1 |
2.1*1.5*2.1 |
2.1*1.5*1.9 |
1.9*1.2*1.8 |
1.9*0.65.1.3 |
Machine weight(Kg) |
4000 |
3500 |
2800 |
2500 |
2000 |
1500 |
1000 |
Reference pictures of Plastic Agglomeration Machine
(all pictures and parameters of PP PE Plastic Agglomeration Machine
for reference only)
