YL31 /31C Provide Road Roller ,vibratory Road Roller , Roller ,double Drums Road Roller

Hangzhou Hexun Industry Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Double Drum Roller

Static Linear Pressure:

13.5KN

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Double Drum Roller

Static Linear Pressure 13.5KN

Travel Speed 0.6km/h,1.2km/h

Grade Ability 30%

Model Number YL31/31C

Dimension(L*W*H) 1460*810*1230MM

Weight 560KG

Certification CE

After-sales Service Provided Overseas third-party support available

Specifications

1.Famous brand engine
2.Imported hydraulic motor
3.Front drum hydraulic turning,turning angle 15degree
4.Sling position

YL31 /31C provide road roller ,vibratory road roller , roller ,double drums road roller

The machine is mainly used to compress on the asphalt, sand soil and gravel. It is also used to planish the lawn.

Famous brand engine, excellent performance, easy to start-up;

Famous Chinese hydraulic pump and motor, forward and backward walking;

Adjusting height mechanism of handrail, storage erectly, easy to transport;

NSK bearing and MITSUBOSHI V-belt;

Automatic centrifugal clutch controlling vibration, easy to operate;

Plastic treated, anti-rust, anti-corrosion and beautiful.

Type	RWYL31	RWYL31C
Run
Speed	0.6km/h, 1.2km/h (Forward and back)
Climbing capacity in theory	30%
Compaction
Static load forward/back	35/38N/cm	37.3/40.3N/cm
Nominal amplitude	0.6mm
Vibration frequency	70Hz
Exciting force	13.5kN
Water tank volume	50L
Working
Drive	Hydraulic pump and motor
Vibration	Manual clutch
Engine
Model	HONDA, GX270	178F
Type	Gasoline engine, air cooled, 4stroke, OHV, single cylinder	Diesel engine, air cooled, 4stroke, vertical type, single cylinder
Power	9.0hp/3600/rpm	6.0hp/3600rpm
Fuel tank volume	6L	5.5L
Dimension
Width of steel wheel	600mm
Diameter of steel wheel	450mm
Tread	600mm
Total length(keep handrail level)	2460mm
Total width	750mm
Total height(keep handrail upright)	1800mm
Packing size	1460x810x1230mm
Weight
Working weight	550kg	570kg
