We could supply all kinds of hydraulic shearer. They adopt advanced hydraulic system, choose imported hydraulic parts, we have rich experiences on hydraulic transmission and control technology, We could design every model according to our customers' requirements, including feeding system, baling system, banding system etc.
1.Applications:
Q15 series of hydraulic alligator shears are applied in recycling companies, automobile dismantling plants, smelting & casting industry to cold-shear section steel and metallic structural parts, to produce acceptable furnace charges.
2.Features:
1. Hydraulic drive, simple operation & easy maintenance
2. Options for different force & blade length.
3. No footing bolts needed, diesel engine optional for power.
4. Hydraulic driven with simple operation, and safe and reliable performace
5. Blade length: 600mm, 700mm, 800mm, 1000mm, 1200mm, 1600mm
6. Eight grades of shear force: 75-500ton
3.Service
(1)one year guarantee and lifelong maintenance.
(2)Any problem you can call us directly.
Certification: ISO9001: 2000 standard&CE
4.Detailed technical specification :
| Type | Q43-200 |
| Max. Shear (t) | 200 |
| Max. material pressure (t) | 30 |
| Knife edge length (mm) | 800 |
| Max. Opening mouth (mm) | 380 |
| Shearing time per min. | 9-12 |
| Dimension of main sheared material | 70×70,φ75 |
| Total power of machine (kw) | 22 |
| Operational method | Manual feeding, manual or automatic |
