Product Details
| Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | DFS |
| Model Number: | Q43-160 | Voltage: | 380V | Rated Power: | 18.5 |
| Dimension(L*W*H): | 2250*800*1450mm | Weight: | 3700 kgs | Certification: | CE |
| Warranty: | One year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1.Product name: scrap metal shearing (High quality )
2.Application:
The Q43 series metal shear machines are mainly applied in recycling companies,automobile dismantling plants,smeltinng and casting industries.They can shear all shapes of profile steels and all kinds of metal into qualified furnance feed materials.
3.Features:
1)Hydraulic driving with easy operation,safe and reliable performance.
2)Blade length:400mm,600mm,700mm,800mm,1000mm,1200mm.
3)Eight levels of shear force:63tons-400tons.
4)No footing bolts needed during installation:use diesel engine when electric power is unavailable.
4.Technical specifications:
Model: | Q43-160 |
Max shear force: | 160tons |
Max material pressure: | 25tons |
Max blade opening: | 320mm |
Blade length: | 700mm |
Shearing frequency: | 8-10times/min |
Dimension of main sheared materials: | 55×55mm,φ63 |
Moter power: | 18.5kw |
Operation method: | manual feeding,manual or automatic |
5.Quality:
The machine applys to ISO9001:2000 standard.
6.Service:
Any problems you can contact us directly.
7.Certificates:
