Product Details
Condition: | New | Production Capacity: | 1-3T | Motor Type: | AC Motor |
Power(W): | 5.5KW-7.5KW | Brand Name: | Kefan | Model Number: | KF-290 |
Dimension(L*W*H): | 1.8*1.2*1.6M | Certification: | CE ISO | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Environmental hemp palm briquette machine
1. Introduction of hemp palm briquette machine :
Four-roller twice pressure briquette machine is suitable for civil and industrial coal production. It features in excellent technical performance, compact structure, reasonable assembly process, special alloy rollers,and long life-span. In addition, it also solves the troubles of low molding pressure and low strength problem in coal briquette production, and can be the ideal machine in this field.
Model: KF-290 |
Power: 5.5-7.5 kw (three phases, 380V, 50HZ) |
Discharging belt conveyor power: 2.2kw |
Diameter of roller:290mm |
Width of the roller: 200mm |
The largest pressure: 5-6T |
Coal capacity: 1-2t/h |
Coke capacity: 1-2t/h |
Charcoal Capacity: 0.6-0.8t/h |
Final briquette diameter: 30-50mm |
Material of roller: 65Mn |
Lifetime of the roller: about 1 year |
Diameter of the gearbox: 350mm |
Applicable materials: cola, charcoal, metal powder, etc. |
Shape of final products: ball, pillow,bread,etc. |
Mode of Operation:Four Rollers Squeezing |
Weight: 700 kg |
Pack size:1.8*1.2*1.6 m |
Excellent hemp palm briquette machine small carbon black briquette machine small coal powder briquette machine with whole line CE:
Working principle of hemp palm briquette machine :
The hydraulic press depends on Pascal's principle: the pressure throughout a closed system is constant. One part of the system is a piston acting as a pump, with modest mechanical force acting on a small cross-sectional area; the other part is a piston with a larger area which generates a correspondingly large mechanical force.
Only small-diameter tubing (which more easily resists pressure) is needed if the pump is separated from the press cylinder. When the pressure on the press cylinder is released (the fluid returning to a reservoir), the force created in the press is reduced to a low value (which depends on the friction of the cylinder's seals.
Main technical parameters of hemp palm briquette machine :
Type | Roll diameter(mm) | Capacity(t/h) | Power(kw) |
KF290 | 290 | 1-2 | 5.5-7.5 |
KF 360-1 | 360 | 2-4 | 7.5-11 |
KF 360-2 | 360 | 8-13 | 30-37 |
KF 400 | 400 | 4-6 | 11-15 |
KF450 | 450 | 6-8 | 22-30 |
KF500-1 | 500 | 8-10 | 22-30 |
KF500-2 | 500 | 8-13 | 30-37 |
KF 650 | 650 | 10-15 | 37-45 |
KF 750 | 750 | 13-18 | 55-75 |
KF 850 | 850 | 15-20 | 75-95 |
Service Advantage of hemp palm briquette machine:
1. we are professional coal briquette machine manufacturer,so we can offer you the machine directly and the factory price.
2.there are stocks in our workshop , Welcome to visit our factory for checking machines
3.We can help you choose the suitable model which one is according to your requirements.
4.Quality control department will provide you good quality machine.Well-equipped facilities for making machines & strict inspection team.
5.Professional export department can give you professional solution from technical negotiation to machine installtaion and delivery.
6.If you need we installate briquette machine ,we will dispatch experience engineer to your site to guide installation and trainning your worker.
24-Hours After-Sale Service: If you have any question when producing, could call the hot-line of our company ,we could help you to solve the problems.
Our certificats of hemp palm briquette machine
FAQ of hemp palm briquette machine
How to choose a suitable coal powder briquette machine:
1. What’s the raw material?
As different materials match different machines, So pls tell us what’s the raw material, is it limestone powder, coal powder or other metal powder.
2. The moisture of raw material ?
The moisture determines whether dryer is needed in the process.
3. The size of raw material ?
It should be crushed if the size is too big.
4. Capacity you need ?
Different capacity match different models of machine, what’s more, the smaller the capacity is, the simpler the process will be.
