High Production Efficiency Stone Trommel Vibrating Screen With Best Quality

Henan Kefan Mining Machinery Co., Ltd.
High Production Efficiency Stone Trommel Vibrating Screen With Best Quality thumbnail-1
High Production Efficiency Stone Trommel Vibrating Screen With Best Quality photo-1
US$ 1,000 - 9,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Circular
Application:
Other, Ore, building and construction industries and so on
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
nearest port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Circular
Application Other, Ore, building and construction industries and so on
Place of Origin Henan, China
Brand Name Kefan
Model Number 2YZS1548
Voltage Industrial voltage
Power(W) 15000
Dimension(L*W*H) 5900*2270*1620
Weight 5.35t
Certification BV/CE/ISO
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Introduction of vibrating screen

The vibrating equipment is an efficient new equipment. The multi-layer vibration equipment for stone quarries and sand filters can also be used as classification processing, building materials, electricity, coal, the role of chemical industry products with the sound vibration of a small, reliable structure, high efficiency, durable, safe and convenient features.

High production efficiency stone trommel vibrating screen with best quality

Working Principle of vibrating screen
Vibrating Screen consists of screen box, supporting device, vibration exciter, transmission part, etc. The barrel-type vibration exciter is installed in the middle  of the machine. During normal operation, the vibration of exciter will drive the screen mesh fixed on the screen box vibrate, and then materials will be screened. The big and small materials fall from the upper side and lower side of the screen to get them separated.

Main Technical Parameters of vibrating screen

Model

Screen Size
(mm)

Screen Decks

Screen Hole Size
(mm)

Max. Feeding Size
(mm)

Capacity
(t/h)

Motor Power
(kw)

Weight
(t)

Overall
Dimension
(mm)

2YZS1237

3700×1200

2

3-50

200

10-80

11

2.40

4773×2050×2247

3YZS1237

3700×1200

3

3-50

200

10-80

11

3.05

4773×2050×2700

2YZS1548

4800×1500

2

3-100

400

30-200

15

5.35

5900×2270×1620

3YZS1548

4800×1500

3

3-100

400

30-200

15

6.07

5900×2270×1670

2YZS1848

4800×1800

2

3-100

400

50-280

18.5

6.15

5900×2560×1620

3YZS1848

4800×1800

3

3-100

400

50-280

18.5

6.93

5900×2560×1670

2YZS1860

6000×1800

2

3-100

400

65-550

22

6.95

7060×2560×1620

3YZS1860

6000×1800

3

3-100

400

65-550

22

7.70

7060×2560×1670

4YZS1860

6000×1800

4

3-100

400

65-550

30

8.70

7060×2560×1930

2YZS2160

6000×2100

2

3-100

400

81-720

22

8.48

7130×2990×1760

3YZS2160

6000×2100

3

3-100

400

81-720

30

9.24

7130×2990×1810

4YZS2160

6000×2100

4

3-100

400

81-720

30

10.45

7130×2990×1930

2YZS2460

6000×2400

2

3-150

400

100-810

30

12.35

7130×4121×1810

3YZS2460

6000×2400

3

3-150

400

100-810

37

13.85

7130×4121×1940

4YZS2460

6000×2400

4

3-150

400

100-810

37

15.60

7130×4121×2080

Relative equipment

High production efficiency stone trommel vibrating screen with best quality High production efficiency stone trommel vibrating screen with best quality High production efficiency stone trommel vibrating screen with best quality High production efficiency stone trommel vibrating screen with best quality
