1. Features:
* Shangchai Caterpillar tech SC11CB220G2B1 engine is adopted, large torque backup and strong power.
*Hangzhou Advance Gear Group WG180 torque converter and fix-shaft gearbox, with ZF technology.
*Electro-hydraulic control, 4 forward and 3 reverse,
*Single lever pilot control system makes operation easy and comfortable.
*Strengthened axles owns large bearing capacities and high reliability.
*Twin pump merging hydraulic system makes lower consumption and excellent performance.
*The coaxes flow-amplified, hydraulic compensated steering makes operation easy and performance reliable.
*Both travel system and working hydraulic system are forced-cooled, improving the efficiency obviously.
*Air over hydraulic brake system; eight caliper disc brakes.
*Air break control, expand hoof type parking brake and emergency brake.
*Large space articulated frame makes operation and traveling stable.
*Working device with automatically leveling ability at high position.
*Main articulated points take sealed, lubricated, dust-proof layers, which owns good durability.
* Integral, luxury instrument board.
* New, luxury cabin
2.Main Specifications:
Item |
Specification |
Item |
Specification |
Bucket capacity |
3m³ |
Min. turning radius(outside of rear wheel) |
6360mm |
Rated load |
5000kg |
Steering angle |
35° |
Dumping height |
3100mm |
Min. ground clearance |
478mm |
Dumping reach |
1280mm |
Wheel base |
3200mm |
Max. speed |
6s |
Wheel tread |
2250mm |
Max. breakout force |
38km/h |
Rated power |
162kW/2200rpm |
Max. breakout force |
170kN |
Tyre |
23.5-25 |
Max. drawing force |
150kN |
Overall dimensions |
7960*3070*3490mm |
Max. grade ability |
28° |
Operating weight |
17000kg |
Remark:Joystick control, electronic control, ZF TECH WG180 gearbox, heavy chassis for standard
3. Quality certificate:
(1)CE Approved.
(2)Obtained the certificate of ISO9001:2008.
(3)Manufacturing license number: TS2510025-2009.
4. Others:
(1)Packing: 1 unit naked within 1 x 40HQ container
(2) Delivery time: 40 days
(3)Accidental benefits: Customers can purchase wearing parts according to the parts list we offered.
(4) Guarantee Period: One year
(5)Offer Validity: 30 days
