1. Features:
* Shangchai Caterpillar tech SC11CB220G2B1 engine is adopted, large torque backup and strong power.
* Single stage, 4 elements, twin turbo ZL50 torque converter and planetary gearbox from Hangzhou Advance Gearbox Group, compact structure and high reliability.
* Gear-shift with 2 forward and 1 reverse controlled by flexible shaft eases much labor.
* Strengthened axles owning large bearing capacities and high reliability.
* Twin pump merging hydraulic system makes lower consumption and excellent performance.
* The coaxes flow-amplified, hydraulic compensated steering makes operation easy and performance reliable.
* Both travel system and working hydraulic system are forced-cooled, improving the efficiency obviously.
* Air over hydraulic brake system; eight caliper disc brakes.
* Air break control, expand hoof type parking brake and emergency brake.
* Working device with automatically leveling ability at high position.
* Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability.
* Integral, luxury instrument board.
* New, luxury cabin
2.Main Specifications:
Item |
Specification |
Item |
Specification |
Bucket capacity |
3m³ |
Min. turning radius (outside of rear wheel) |
6360mm |
Rated load |
5000kg |
Steering angle |
35° |
Dumping height |
3100mm |
Min. ground clearance |
478mm |
Dumping reach |
1285mm |
Wheel base |
3200mm |
Boom lifting time |
6.8s |
Wheel tread |
2250mm |
Max. speed |
36km/h |
Rated power |
162kW/2200rpm |
Max. breakout force |
170kN |
Tyre |
23.5-25 |
Max. drawing force |
150kN |
Overall dimensions |
7960*3070*3490mm |
Max. grade ability |
28° |
Operating weight |
17000kg |
Remark:Heavy chassis for standard
3. Quality certificate:
(1)CE Approved.
(2)Obtained the certificate of ISO9001:2008.
(3)Manufacturing license number: TS2510025-2009.
4. Others:
(1)Packing: 1 unit naked within 1 x 40HQ container
(2) Delivery time: 40 days
(3)Accidental benefits: Customers can purchase wearing parts according to the parts list we offered.
(4) Guarantee Period: One year
(5)Offer Validity: 30 days
