Help Center3 Ton Loader With Cumins Engine
Related Products
-
YN939 Shovel LoaderNegotiableMOQ: 1 Piece -
YN938 Shovel LoaderNegotiableMOQ: 1 Piece
-
YN935 Shovel LoaderNegotiableMOQ: 1 Piece
-
3 Ton 938 Wheel LoaderNegotiableMOQ: 1 Piece
-
ZL30 Wheel Loader OEM Supplier Mini Wheel Loader YN938 SHAN DONG Yineng Luneng Machinery LN YN CE APPROVEDUS$ 30,000 - 30,005MOQ: 1 Set
FEATURES AND OPTIONALS:
*CUMMINS diesel engine, higher power and reliability.
*Hydrodynamic transmission, three-element and single stage torque converter, high reliability, easy maintenance.
*Hangzhou Advance Gearbox Group BS428 powershift transmission, high efficiency and easy maintenance.
*Gear-shift controlled by flexible shaft makes operation more flexible and reliable.
*Single lever joystick control system, comfortable and flexible operation.
*Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoids oil leakage obviously;
* Air over hydraulic disks on four wheel brakes.
*Large space articulated frame makes operation and traveling stable.
*Working device with automatically leveling ability at high position.
*Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability.
*Integral, luxury instrument board.
*New, luxury cabin.
STANDARD SPECIFICATIONS: Item |
Specifications |
Item |
Specifications |
Bucket capacity |
1.8 m3 |
Min. turning radius (outside of rear wheels) |
5160mm |
Rated load |
3000 kg |
Steering angle |
36º |
Dumping height |
3000 mm |
Min. ground clearance |
375mm |
Dumping distance |
1100 mm |
Wheel base |
2700mm |
Boom lifting time |
5.5 S |
Tread |
1865mm |
Total cycling time |
10 S |
Engine model |
6BT5.9-C130 |
Max. speed |
36 km/h |
Rated power |
97kW/2300rpm |
|
Max. breakout Force |
120 kN |
Tyre specifications |
17.5-25 |
Max.drawing force |
90 kN |
Overall dimensions |
7020*2510*3300mm |
Max. Gradeability |
30° |
Operating weight |
10600kg |
<![if !supportLists]>4- <![endif]>QUOTATION:
YN938 Wheel Loader (Standard model with 1.8 m³, 3.0 ton Capacity, Cummins engine, Hydrodynamic transmission, Joystick control, Large space articulated frame)
FOB Qingdao Port, $29000.00
Optional:
YD13 Gearbox (electronic control, ZF tech) +$2,800.00
Air Condition +$780.00
Quick Hitch +$1000.00
Pallet Fork +$660.00
Delivery period: 30 days
Validity of offer: 30 days.
Payment terms: T/T or L/C at sight.
Packing: 1 piece disassembled, naked within 1 x 40HQ container.
2 pcs disassembled, naked within 1 x 40HQ, 1 x 20’ GP containers.
HS Code: 8429510000
MOQ: 1 unit
Guarantee:
We will send free spare parts with each loader. Besides, customers can order spare parts according to the parts list we offered.
Guarantee period: 12 Months from the shipping date.
