1. Features:
* YTOLR4B3-24 diesel engine is adopted, with strong power.
* Applying hydrodynamic transmission technology, single stage, 3 elements torque converter owns simple structure and high reliability.
* Controlled by flexible shaft, hydraulic power shift gearbox with 2 forward and 2 reverse gears makes operation easy.
* Single pump, split flow working hydraulic system makes lower consumption and excellent performance.
* Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoiding oil leakage;
* Load sensing fully hydraulic steering system makes operation easy.
* Air over hydraulic brake system; Caliper disc brakes.
* Working device with automatically leveling ability at high position.
* Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability.
* Integral, luxury instrument board.
* New, luxury cabin.
2.Main Specifications:
Item |
Specification |
Item |
Specification |
Bucket capacity |
1.1m³ |
Min. turning radius (outside of rear wheel) |
4600mm |
Rated load |
2000kg |
Steering angle |
35° |
Dumping height |
2750mm |
Min. ground clearance |
320mm |
Dumping reach |
920mm |
Wheel base |
2350mm |
Boom lifting time |
5s |
Wheel tread |
1500mm |
Max. speed |
25km/h |
Rated power |
60kW/2400rpm |
Max. breakout force |
48kN |
Tyre |
16/70-20 |
Max. drawing force |
45kN |
Overall dimensions |
5880*2060*2750mm |
Max. grade ability |
30° |
Operating weight |
6000kg |
3. Quality certificate:
(1)CE Approved.
(2)Obtained the certificate of ISO9001:2008.
(3)Manufacturing license number: TS2510025-2009.
4. Others:
(1) Packing: 2 units naked within 1 x 40HQ container
(2) Delivery time: 30 days
(3) Accidental benefits: Customers can purchase wearing parts according to the parts list we offered.
(4) Guarantee Period: Six Months
(5)Offer Validity: 30 days
