Specifications
Harvester1.Pick corns, Smashing the straw
2.Remove covers of corn
3.Easy to operate
4.Good quality, High efficiency
Harvester
1. Function:
- pick corns, remove the cover of corn
- smash corn stalks
- return the smashed corn stalks to field
2. Features:
- Header: adopt advance technology of Ukraine. 14 years market test.
- Increased walking gear box.
- Brand-name and high-quality engine
- Air filter: increase pre-filter device
- Radiator: closed type, maintenance-free
- Reinforced rear axle
- Optimized and upgraded peeling machine
3.Technical Parameter:
Item |
Unit |
4YZ-4B(600) |
Structural style |
/ |
Self-propelled |
Harvesting rows |
row |
4 |
Header standard line spacing |
mm |
600 |
Working width |
mm |
2700 |
Suitable line spacing |
mm |
450-650 |
Mini ground clearance |
mm |
300 |
Driving wheel track |
mm |
1640 |
Steerable wheel track |
mm |
1640 |
Mini turning radius |
mm |
Left:8900,right:9500 |
The max height of driving pass |
mm |
3550 |
Engine |
model |
YC4A147L-T20 |
|
Rate speed(r/min) |
2300 |
|
Power (Kw/hp) |
108/147 |
Working speed |
Km/h |
3-6 |
Working efficiency |
ha/h |
0.4-0.9 |
Barn cubage |
M3 |
2.5 |
Oil consumption |
Kg/hm2 |
≤50 |
Unloading height |
mm |
2000 |
Type of stalk pulling roller |
/ |
Six edge type |
Peeling roller type |
/ |
Rubber roller,iron roller |
Fan |
Type |
Vane type |
|
Diameter |
390mm |
|
Quantity |
1 |
Type of chopper |
/ |
Horizontal Rotary cuter shaft,flail knife |
Type of gear box |
/ |
Mechanical |
Tyre |
Model |
Front:15-24;rear:10/75-15.3 |
|
Air pressure(kpa) |
Front:280;rear:400 |
I gear |
Km/h |
1.55-3.45 |
II gear |
Km/h |
3.43-7.61 |
III gear |
Km/h |
9.25-20.51 |
Reverse gear |
Km/h |
3.62-8.03 |
Grain loss rate |
/ |
≤2% |
Ear loss rete |
/ |
≤3% |
The seed broken rate |
/ |
≤1% |
Stubble height |
mm |
≤100 |
The peeling rate |
|
≥85% |
Reliability |
/ |
≥90% |
Whole weight |
kg |
6900 |
Overall dimension(L*W*H) |
mm |
8120x2750x3550 |
