Horizontal Semi-automatic Solid Bar Thread Rolling Machine S310
- ShenZhen
- T/T D/P D/A Credit Card
You May Like
-
Thread Rolling Machine Thread Roller With 10-1000mm Thread Rolling LengthTB-16GT
-
2017 New Type Cheap Thread Rolling Machine for Different Rod Diameter
-
Best Quality Taper Thread Rolling Machine TB-3S
-
Screw Rolling Machine With 12-80mm Thread Rolled Diameter TB-40S
-
High Speed Automatic Rebar Thread Rolling Machine CGR-5RH
-
High Speed Automatic Pipe Thread Rolling Machine CGR-253H
Product Details
| Application | Bars | Production Capacity | Month | |
| Place of Origin | Guangxi, China | Model Number | s310 | |
| Voltage | 380V/220V | Power(W) | 4kw | |
| Dimension(L*W*H) | 1100x550x850mm | Weight | 250kg | |
| Certification | ISO CE | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Horizontal semi-automatic solid bar thread rolling machine S310
Thread rolling machine with solid structure, sophisticated manufacturing, reasonable price,so welcomed by the users. And Suitable for cold state straight grained, thread, twill be rubbing molding. This machine easy to use, reasonably priced, and well received by users. Is the production of non-standard thread, standard pipe thread ideal equipment
Feature
1.Semi-automatic vertical roller is mainly used in wire machine without a head of long rod, the Semi-automatic of work, can achieve more than one machine and effectively reduce the labor cost.
2.Mainly used in U bolt, stud bolt, rearview mirror bar, a knife, feed length can reach about 700mm. (can be customized according to customer products)
3.According to the product with cutting function (custom) to realize cutting thread integration, automatic equipment.
4.This machine is with Taiwan technology to ensure the equipment parts, reasonable design efficient and durable.
Technical parameter
type | S206 | S310 | S312 | S416 | S518 | S520 | S524 |
range of work | M2-M6 | M3-M10 | M4-M12 | M4-M16 | M5-M18 | M5-M20 | M5-M24 |
working efficiency | 42-70 Pcs / min | 42-70 Pcs / min | 42-70 Pcs / min | 42-70 Pcs / min | 42-70 Pcs / min | 30-60 Pcs / min | 30-60 Pcs / min |
filament plate size | 125×40×25mm | 175×50×30mm | 170×50×30mm | 220×60×40mm | 250×70×45mm | 250×80×45mm | 400×105×50mm |
Selection motors | 2kw | 3kw-4kw | 3kw-4kw | 4kw-7.5kw | 4kw-7.5kw | 7.5kw-11kw | 11kw-15kw |
outline dimension | 850×520×700mm | 1100×550×850mm | 1100×550×850mm | 1600×700×850mm | 1600×700×850mm | 1650×700×1100mm | 2100×910×1200mm |
weight | 125kg | 250kg | 250kg | 500kg | 600kg | 700kg | 1200kg |
Detailed pictures for your reference
We will pack the machine with standard export wooden case ,ensure the transport safety
A: You can choose FOB,CIF, DDU or other terms. You can book ship or I can book ship for you.
A: You can make the inquiry online on Alibaba, or send email to us. It is better if you can tell what is your detailed request information. We will reply to you within 2 hours on work days, and within 24 hours on holiday.
A: You can choose machine on our website accodring to your request. Or You can let our seller know what is your request specifcation or what is your parts, so let our seller recommend suitable machine to you. We have do trade machine years, and export machine to over 100 countries. We have CE, ISO, SGS and other quality certificate.
A: We can make the deal on Alibaba online platform, you can pay by T/T or Credit card. You can also pay to my company business bank account. You can also choose L/C or other way.
A: If the machine you will order is standard machine, we can ready the machine within 15days. If special machine, please confirm with our seller. The ship time is about 30 days to Europe, America. If you are from Australia, or Asia, it will be shorter. You can place order according to delivery time and ship time.
A: warranty is one year, but we will offer lifetime service for machine.
