Specifications
1.excellent performance2.Black electrocoating, super strong resistance
3.Bundy tube(steel tubes coated with copper)
Refrigerator Condenser
1. Bundy tube diameter Φ4.76-8mm, thickness 0.6-0.71mm
2. Low Carbon wire diameter Φ1.2mm--Φ1.6mm
3. Two layers or more layers
4. Fan assembling place can be added
5. Surface with electrophoretic coating, thickness 10-25micrometer,black
6. The tube ends sealed with rubber cap
7. Dry nitrogen in the tube
8. Inner cleanness
9. Bundy and wires can be adjusted according to customers' requirements, drawings and samples
R134A Cooling System Tube Inside Standards:
Residual moisture Residual moisture≤ 5 mg/100cm3
Residual impurity≤ 10mg /100cm3
Residual mineral oil≤ 100 mg /100cm3
Residual chlorine≤ 5vloppm
Residual paraffin≤ 3mg/m2
Biggest single impurity≤ 0.5mm
Structure: Flat;Folded;Wave Flow,Compact; or other OEM design based on customer drawings
Package: Carton box or wooden box
Delivery Time: 30-35 days after receive your 30% deposit
PRODUCT PICTURE:
PACKING PICTURE:
