Deep Freezer Refrigerator Wire Tube Condenser / Wire on Tube Condenser / Refrigerator Condenser

Deep Freezer Refrigerator Wire Tube Condenser / Wire on Tube Condenser / Refrigerator Condenser thumbnail-1
Deep Freezer Refrigerator Wire Tube Condenser / Wire on Tube Condenser / Refrigerator Condenser photo-1
US$ 1 - 2 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Partsnet
Model Number:
NPTC-RC02
Contact Supplier Request Quote Chat Now
Ningbo Partsnet Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Partsnet
Model Number NPTC-RC02
Type Other, Conderser,Refrigeration & Heat Exchange Parts
Application Refrigeration Parts
Certification CE

Deep freezer refrigerator wire tube condenser / wire on tube condenser / refrigerator condenser







Application



There are generally two types of condensers, fin type condenser (fan cool ) and tube type condenser ( fan cool ). An air conditioning condenser is used to convert hot and high pressure refrigerant gas to a subcooled liquid. In the fin type condensers, the gas refrigerant run through the copper pipes and the heat is removed from the  aluminum foils with the function of fans. And for the tube type condenser, the heat is removed when the refrigerant go through the bundy tubes.



1 . Refrigerator, freezer
2 . Commercial and home ice maker.
3 . Refrigerating showcase



Specification



1. Material: Bundy tube (steel tubes coated with copper):4.76mm×0.71mm, 6.35mm×0.71mm, 8mm×0.71mm

2. Steel wires 1.0mm-2.0mm  (both sides can be with steel plates and brackets; can be upon your choice)

3. Structure: bundy tubes welded with steel wires

4. Painting: Cathode electrophoretic painting (black)

5. With rubber caps at both ends.

6. We can supply the items according to customers' drawings or samples.





Model Length(A) Width U-bends Nos Rows Wire Qty Wire len1160gth
1/3 HP 1150 485&425 12 24 126/108 1160
1/4 HP 1050 485&425 11 22 126/108 1060
1/5 HP 950 485&425 10 20 126/108 960
1/6 HP 850 485&425 9 18 126/108 860
1/7 HP 750 485&425 8 16 126/108 760
1/8 HP 650 485&425 7 14 126/108 660
1/9 HP 560 485&425 6 12 126/108 560
1/10 HP 550 485&425 5 10 126/108 460
1/12 HP 350 485&425 4 8 126/108 360





Packaging & Delivery



Packaging Detail: standard export packaging,Its also Depending on Clients Requests.



Delivery Detail: 20-30days after receiving the deposit





Payment: L/C , T/T





Shipment: 30 days after receiving 30% deposit





Deep freezer refrigerator wire tube condenser

Deep freezer refrigerator wire tube condenser / wire on tube condenser / refrigerator condenser



Wire on tube condenser

Deep freezer refrigerator wire tube condenser / wire on tube condenser / refrigerator condenser



Refrigerator condenser

Deep freezer refrigerator wire tube condenser / wire on tube condenser / refrigerator condenser
