Place of Origin Zhejiang, China
Brand Name partsnet
Model Number CD 60 series
Condition New

Specifications



1.Used widely in motors,air conditioner ,water pump etc 2.High performance & Long life Capacitor. well even in hot area


MS Series Start Capacitor(CD60 Capacitor)

Features:
1.Round type
2.Bakelite or plastic case

Item No. MFD Voltage   Item No MFD Voltage
MS88-108A 88-108 110 125 MS88-108B 88-108 220 250
MS108-130A 108-130 110 125 MS108-130B 108-130 220 250
MS124-149A 124-149 110 125 MS124-149B 124-149 220 250
MS130-156A 130-156 110 125 MS130-156B 130-156 220 250
MS145-175A 145-175 110 125 MS145-175B 145-175 220 250
MS161-193A 161-193 110 125 MS161-193B 161-193 220 250
MS189-227A 189-227 110 125 MS189-227B 189-227 220 250
MS216-259A 216-259 110 125 MS216-259B 216-259 220 250
MS233-280A 233-280 110 125 MS233-280B 233-280 220 250
MS243-292A 243-292 110 125 MS243-292B 243-292 220 250
MS270-324A 270-324 110 125 MS270-324B 270-324 220 250
MS324-388A 324-388 110 125 MS340-408B 340-408 220 250
MS340-408A 340-408 110 125 MS378-454B 378-454 220 250
MS378-454A 378-454 110 125 MS440-480B 440-480 220 250
MS400-480A 400-480 110 125
MS430-516A 430-516 110 125
MS460-552A 460-552 110 125
MS540-648A 540-648 110 125 MS72-86C 72-86 330
MS590-708A 590-708 110 125 MS88-108C 88-108 330
MS645-774A 645-774 110 125 MS108-130C 108-130 330
MS708-850A 708-850 110 125 MS124-149C 124-149 330
MS720-864A 720-864 110 125 MS130-156C 130-156 330
MS829-995A 829-995 110 125 MS145-175C 145-175 330
MS850-1020A 850-1020 110 125 MS161-193C 161-193 330
MS1000-1200A 1000-1200 110 125 MS189-227C 189-227 330



Main Feature:
1.Bakelite case

2.Voltages from 110V AC to 330V AC



Applicable Scope :
To start and run single phase m0tors in alternating current usage,
And it suit for single phase A.C. motors with frequency of 50/60Hz.

General Specifications:
Operating Temperature:-25~+65°C
Voltage Range:110~330V AC
Capacitance Range:21~1280μf
Capacitance Tolerance:+/-20%
Operate Frequency:50/60Hz

Product Description
CD60 start capacitor is developed and researched according to standard of American
Electronics Association (ANSI/EIA-463).The external case of the capacitor is made of
bakelite plasticized which Character is not only good insulating resistance. strong resistance damaged but also protecting electro liquid as good sealed feature. It is popular
used for the super AC application as good life, higher degree of reliability and stability.
