Home > Electrical & Electronics > Passive Components > Capacitor > AC Motor Run Capacitor / CBB65 Aluminum Capacitor
US$ 0.5 - 2
MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Partsnet
Model Number:
NPTC-CBB65
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Air Conditioner Motor Run Capacitor CBB65 250V/370V/440VUS$ 0.9 - 1.5MOQ: 500 Pieces -
Washing Machine Capacitor, High Quality Washing Machine Capacitor, 4 Wires Washing Machine CapacitorUS$ 2 - 5MOQ: 400 Parcels
-
Fan Run Capacitor /DIP Fan Capacitor/PTC CapacitorUS$ 0.1 - 5MOQ: 1000 Pieces
-
Capacitor for A/C and Refrigeration PartsUS$ 0.1 - 5MOQ: 1000 Pieces
-
Hard Starting Kit/Refrigeration Spare Parts HS Series Hard Start Kit /hard Start Capacitor KitUS$ 8.5 - 15MOQ: 1000 Pieces
Place of Origin
Zhejiang, China
Brand Name
Partsnet
Model Number
NPTC-CBB65
Type
Aluminum Electrolytic Capacitor
Application
AC / Motor
Package Type
Surface Mount
Capacitance
5UF-100UF
Rated Voltage
250V-450V
Operating Temperature
25/70/21
Specifications
1.CE,TUV,UL & ROHS proved2.Good capacitance stability
Product Name:AC Motor Run Capacitor
Specifications:
1.Made of aluminium body
2.Filled by oil of good sealing
Technical Features:
1)·Technical features: climate types,40/70/21or40/85/21
2).Capacity deviations,±5%
3)·Insulation resistance,≥3000S(MΩ·μF)
4)·Loss tangent,tgδ≤0.002(50Hz~100Hz)
5).Use requirements
·Altitude,≤2000m
·Residual voltage inputs,≤rated voltage10%
Maximum allowable voltage,≤110% rated voltage
·Maximum allowable current,≤130%Times rated current
| Model | Microfarad | Frequency | Temperature | Voltage | Size(Dia.xheight) |
| NPTC-RARC402 | 2uf | 50/60HZ | -25°C-70°C | 370V | 40x60mm |
| NPTC-RARC403 | 3uf | 50/60HZ | -25°C-70°C | 370V | 40x60mm |
| NPTC-RARC404 | 4uf | 50/60HZ | -25°C-70°C | 370V | 40x60mm |
| NPTC-RARC405 | 5uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC406 | 6uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC407 | 7uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC408 | 7.5uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC409 | 8uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC410 | 9uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC411 | 10uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC412 | 11uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC413 | 12uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC414 | 14uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC415 | 15uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC416 | 16uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC417 | 17.5uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC418 | 18uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC419 | 20uf | 50/60HZ | -25°C-70°C | 370V | 40x70mm |
| NPTC-RARC420 | 25uf | 50/60HZ | -25°C-70°C | 370V | 45 x 90mm |
| NPTC-RARC421 | 30uf | 50/60HZ | -25°C-70°C | 370V | 45 x 90mm |
| NPTC-RARC422 | 33uf | 50/60HZ | -25°C-70°C | 370V | 45 x 90mm |
| NPTC-RARC423 | 35uf | 50/60HZ | -25°C-70°C | 370V | 45 x 90mm |
| NPTC-RARC424 | 40uf | 50/60HZ | -25°C-70°C | 370V | 50 x 100mm |
| NPTC-RARC425 | 45uf | 50/60HZ | -25°C-70°C | 370V | 50 x 100mm |
| NPTC-RARC426 | 50uf | 50/60HZ | -25°C-70°C | 370V | 50 x 110mm |
| NPTC-RARC427 | 55uf | 50/60HZ | -25°C-70°C | 370V | 50 x 125mm |
| NPTC-RARC428 | 60uf | 50/60HZ | -25°C-70°C | 370V | 50 x 125mm |
| NPTC-RARC429 | 70uf | 50/60HZ | -25°C-70°C | 370V | 50 x 125mm |
| NPTC-RARC430 | 80uf | 50/60HZ | -25°C-70°C | 370V | 60 x 120mm |
| NPTC-RARC431 | 90uf | 50/60HZ | -25°C-70°C | 370V | 64 x 130mm |
| NPTC-RARC432 | 100uf | 50/60HZ | -25°C-70°C | 370V | 64 x130mm |
| Votage: 250V and 440V are also available. | |||||
