Help CenterRefrigerator Defrost Thermostat / KSD Series Thermostat
Related Products
-
Defrost Thermostat (KSD-3001)US$ 0.71 - 1.18MOQ: 1000 Pieces -
Defrost Thermostat (KSD-3002)US$ 0.71 - 1.18MOQ: 2000 Pieces
-
Defrost Thermostat (KSD-3003)US$ 0.71 - 1.18MOQ: 2000 Pieces
-
Defrost Thermostat (KSD-4008)US$ 0.71 - 1.18MOQ: 2000 Pieces
-
Defrost Thermostat (KSD-7008)US$ 0.71 - 1.18MOQ: 2000 Pieces
Specifications
1.Auto reset with ceramic or plastic body2.Electrical Ratings: AC250V /125V,5A/10A/16A
3.Normally closed or normally open
Refrigerator Defrost Thermostat
1.Applications:
Refrigerators,Show Case (cold storage, freezing, thermal insulation),Ice Maker, etc
2.Function :
Automatic temperature control for removing frost and for protecting the frozen rupture in the cold storage or freezing
3.Temperature feature:
a) Rated Action Temperature: 0 °C---210 °C (Designed by user's requirements)
b) Open Tolerance: ±2°C, ±3 °C, ±4 °C, ±5°C
c) Open & Close Tolerance: 5 °C -60 °C
d) Close Tolerance: ±2°C, ±3 °C, ±4 °C, ±5°C, ±10 °C
e) Normal Electric Strength: Not Broken within 2000V / 1 minute, No flash.
f) Normal Isolated Resistance: >100M Ω
Easy to install at the small or narrow space
Slim shape -Small size with high contacting capacitance
Available waterproof and dustproof types with welding vinyl tube on the parts
Remarks : Any requirement on the terminals, caps, brackets or contacts are acceptable
