Hydraulic 500 Ton Wire Rope Press Machine
US$ 5,000 - 15,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
BOBO
Model Number:
GT-500
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hydraulic 300Ton Wire Rope Press MachineUS$ 5,000 - 15,000MOQ: 1 Set -
Hydraulic 350 Ton Wire Rope Press MachineUS$ 5,000 - 15,000MOQ: 1 Set
-
Hydraulic Wire Rope Ferrule Press MachineUS$ 5,000 - 15,000MOQ: 1 Set
-
2000 Ton Hydraulic Steel Wire Rope Sleeve Press MachineUS$ 5,000 - 15,000MOQ: 1 Set
-
1500Ton Hydraulic Steel Wire Rope Sling Making MachineUS$ 5,000 - 15,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
BOBO
Model Number
GT-500
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Hydraulic 500 ton wire rope press machine1- Closed type structure
2- Quick installation
3- Digital display,PLC control
Hydraulic 500 ton wire rope press machine
The hydraulic 500 ton wire rope press machine is widely used in oil fields, ports, railways, construction and other related fields. The finished lock has stable tension, heavy loading capacity feature.
Feature
Cylinder embedded design
Round independent mold
- Adjustable piston stroke
- High technology and strength
Main technical data
| 1 | Model | GT-500 |
| 2 | power | 5000KN |
| 3 | Max. wire rope diameter | 32/ 42mm |
| 4 | Max. working pressure | 28MPa |
| 5 | Max. piston stroke | 120mm |
| 6 | Work speed | 4.5mm/s up and 8mm/s down |
| 7 | Motor capacity | 11kw |
| 8 | Dimension | 1600x680x1800mm |
| 9 | Net Weight | 3000kg |
