Home > Instruments & Meters > Test Instrument > Test Machine > Wheel Nut Seat Axial Strength Testing Machine
US$ 10,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
BOBO
Model Number:
BCS-3
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hydraulic Wheel Rim MachineUS$ 25,000 - 40,000MOQ: 1 Set -
Wheel Roll Bending MachineUS$ 25,000 - 40,000MOQ: 1 Set
-
Hydraulic Wheel Welding MachineUS$ 80,000 - 200,000MOQ: 1 Set
-
Flash Butt Welding Machine for Steel Wheel RimUS$ 85,000 - 200,000MOQ: 1 Set
-
800KVA Wheel Welding MachineUS$ 85,000 - 200,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
BOBO
Model Number
BCS-3
Power
Electronic
Usage
Strength Testing Machine
Specifications
This wheel nut seat axial strength testing machine is used to evaluate the axial strength of nut seat of passenger cars wheel.
Wheel nut seat axial strength testing machine
The wheel concering fatigue testing machine is designed based on ISO, SAE, JIS, ect standards, widely used for car wheel, truck and bus wheel dynamic concering fatigue testing.
Main technical data
- Wheel nominal diameter: 12"~26"
- Wheel nominal width: 4"~12"
- Wheel offset range: 0~165mm
- Maximum load: 66kN
- Maximum measuring stroke: 25mm
- Operating voltage: 220V AC 50Hz
- Rated power: <0.1kW
- Dimension: 1488mm L X 1100mm W X 1725mm
- Machine total weight: ca.2.4t
Key word: Wheel impact testing machine, wheel testing machine, impact tester, wheel radial fatigue testing machine, wheel cornering fatigue testing machine, wheel nut seat strength testing machine.
