Hydraulic wheel welding machine
- 6 Set / Sets per Month
- Shanghai
- T/T Credit Card
- LIVTER Pneumatic Model Welder Machine Band Saw Welder For Welding Band Saw Blade
- LIVTER High Frequency Welding Machine Butt Welders Ubn Band Saw Welding Machine
- LIVTER High Frequency Saw Blade Welding Machine Butt Welding Machines For Band Saw Blades
- LIVTER 220v household saw blade welding machine UN-10 copper rod aluminum wire butt welding machine
- LIVTER Saw Blade Touch Welder Woodworking Welding Annealed Steel Butt Welder
- 0.2-32mm butt welding machine for welding stainless steel rib aluminum copper wire iron wire
Product Details
Condition: | New | Brand Name: | BOBO | Model Number: | UN-800-1200KVA |
Input Voltage: | 380V | Current: | N/A | Power: | 800KVA |
Dimensions: | 2600X2450X1690mm | Usage: | Wheel rim butt welding | Certification: | ISO |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Hydraulic wheel welding machine1- butt welding
2- auto clamp
3- auto flashing
4- auto forging
Hydraulic wheel welding machine
Car Industry- wheel making machine
Wheel hydraulic flash butt welding machine
Feature
- For hydraulic type butt welding machine. The work piece will be clamped by clamp tools in hydraulic
- Adopts NC control system to operate hydraulic forging and melting device. All technical data adjusted by digital signal, to set data exactly and easily.
- Work process is controlled by PLC, include press out, relax, melting and forging etc. Also emergency alarm for water-short and air pressure-short, etc. Man-machine screen show all the data and adjustments.
- Design with independent cooling system and centralized water-supply, to ensure transformer, electrode and clamp tools cool very well.
- UN-800KVA hydraulic flash butt welding machine is suitable for 22-32” wheel rim.
- This hydraulic type butt welding machine. The work piece will be clamped by clamp tools in hydraulic
Main technical data
Rated capacity | 1200KVA |
Primary supply | 380V / 50hz/1phase |
Welding section | 5000mm2 |
Welding width | Max. 520mm |
Welding thickness | Max. 8mm |
Adjusting series of primary supply | 8 grade (7-14V) |
Duty cycle | 50% |
Cooling water pressure | ≥0.2Mpa |
Cooling water temperature | <25°C |
Cooling water consumption | ≥3000L/h |
Air pressure | ≥0.4Mpa |
Productivity | 400-600 pieces/shift |
For car, tractor wheel welding purpose, up to 32" steel wheel.
