Passenger Car Wheel Impact Testing Machine

Specifications

Wheel impact testing machine is used for car wheel impact test in 30/90 degree, which is designed based on JIS4103-1988 standard

 passenger car wheel impact testing machine



Wheel impact testing machine is used for car wheel impact test in 30/90 degree, which is designed based on JIS4103-1988 standard



Main technical data

• Machine is made of high steel;
• Motor driving and precision lead screw guide system
• Test wheel diameter range: 12"~26", width range: 4"~12";
• Maximum dropping height: 500mm;
• Striker completes with releasing device, which can drop freely;
• Main striker: 910±18kg
• Weight: 100±4.5kg
• Synthetic spring constant: 0.98-1.3kN/mm
• Initial flexiblity: 6mm
• Spring number: 3PCS
• Striker adjustable dropping height, dropping height: ≥500;
• Striker impact section area: 380X152mm, striker side chamfer radius 5mm;
• Wheel support center locates at the center of striker transversal plane.
