Home > Manufacturing & Processing Machinery > Machine Tools > Punching Machine > Wheel Rim Plant Machine
US$ 20,000 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
BOBO
Model Number:
WTM-I/II
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangsu, China
Brand Name
BOBO
Model Number
WTM-I/II
Specifications
The wheel rim plant machine include mainly:1- Wheel roll bending
2-Wheel butt welding
3-wheel flaring
4-Wheel roll forming
Wheel rim plant machine
Wheel rim making machine, wheel rim machine, wheel rim plant
Wheel flash butt welding machine- hydraulic type
Main technical data
1. Rated power: 400KVA
2. Primary welding voltage: 380V
3. Secondary welding voltage: 5.4-9.7V
4. Duty cycle: 60%
5. Max. clamping force: 30T (500KN)
6. Max. Forging force: 15T (200KN)
7. Cooling water pressure: ≥0.2Mpa
8. Cooling water temperature: <25°C
9. Cooling water consumption: ≥3500L/h
10. Air pressure: ≥0.4Mpa
11. Clamp open stroke: 20-40mm
12. Welding speed: 5 pics/ min
Nominal trimming force | Kg | 13000 |
Stroke of blade rod | Mm | 700 |
Ram stroke | Mm | 100 |
Motor power | KW | 15 |
Cycle times | Times/pic | 5 |
Dimension | Mm | 3200×1450×1700 |
Weight | kg | 3000 |
please contact us for more details
