Help CenterCar Wheel Ovality Measuring Machine
US$ 10,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
BOBO
Model Number:
BYS-5
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Tractor Wheel MachineUS$ 50,000 - 120,000MOQ: 1 Set -
Wheel Rim Making MachineUS$ 40,000 - 200,000MOQ: 1 Set
-
Agricultural Wheel Rolling MachineUS$ 40,000 - 86,000MOQ: 1 Set
-
Agricultural Wheel Rim Production LineUS$ 500,000 - 1,000,000MOQ: 1 Set
-
Hydraulic Wheel Flaring MachineUS$ 50,000 - 70,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
BOBO
Model Number
BYS-5
Power
Electronic
Usage
Strength Testing Machine
Specifications
This measurement machine is used to measure the radial and axial run-out of wheel and analyze the harmonic wave. car wheel ovality measuring machine
This measurement machine is used to measure the radial and axial run-out of wheel and analyze the harmonic wave. Which is designed based on ISO 16833:2006 Road vehicles — Wheels — Measurement of radial and lateral run-out standard
Main technical data
- Wheel nominal diameter: 16”~25”
- Wheel nominal width: 5”~14”
- Center hole diameter: φ160,φ221,φ28
- Radial measuring accuracy solution: ≤0.2 mm
- Machine repeatability accuracy: 0.05mm
- Load cell capacity: ±10 mm
- Machine Position method: Floating cone style
- Checking method: Hard roller (Steel GCr15) in the contacting way.
- Sensor slide plate moving: done by pneumatic part.
- Sensor moving: done by pneumatic part
- Main shaft rotating drive: manual
- Wheel tightening: manual
- Power consumption: <1 kw
- Compressed air: 0.4~0.6MPa
- PC deals with data saving, statistics, and printing.
- Display of first and second harmonic wave
- Main machine weight: about 800kg
- Main machine dimension: 1350 mm×610 mm×1350 mm
Key word: Wheel impact testing machine, wheel testing machine, impact tester, wheel radial fatigue testing machine, wheel cornering fatigue testing machine, wheel nut seat strength testing machine.
