Specifications
1.Good abrasive resistance .2. High impact &wear resistance .
3. Good heat and corrosion resistance
4.Low price
Our products including the following:
i.Powder metallurgy dies:
1.Non-Ferrous metal moulds: like gear finished die,sizing die,automobile parts,motor driven tool parts,etc.
2.Magnaglo moulds: like E shape dies,U shape dies,PM shape dies,G shape dies,etc.
3.Tungsten carbide moulds: like wire-drawing die,indexable inserts dies,mining tools dies,squeezing die,steel die,etc.
ii.Kinds of tungsten carbide TF products:
1.Tungsten carbide nonstandard dies: like cold heading dies,battery dies,carbide blanking dies,stretching die,etc.
2.Tungsten carbide wear parts:carbide rollers,carbide gauge,tungsten carbides inserts,carbide roll collar,carbide plug gauge,etc.
ii.Tungsten carbide products:carbide board,Bars,etc
If you are interested in our goods,please don't hesitate to contact us for further information.You shouldn't miss it!
| Brazed turning inserts | ||||||||
| Grade | ISO Code | Performance | Performance&application recommended | |||||
| Density | Bend Strength | Hardness | ||||||
| G/Cm3 | N/mm2 | HRA | ||||||
| YG3 | K05 | 15.1 | 92 | 1400 | Suitable for finishing of cast iron and nonferrous metal. | |||
| YG6X | K10 | 14.95 | 91.5 | 1800 | The finishing&semi-finishing of cast iron and nonferrous metals and also | |||
| for the machining of manganese steel and hardening steel. | ||||||||
| YG6 | K15 | 14.95 | 90.5 | 1900 | Suitable for the roughing of cast iron and light alloys and also for the | |||
| YG8 | K20 | 14.8 | 89.5 | 2200 | milling of cast iron and low-alloy steel. | |||
| YW1 | M10 | 13.1 | 91.6 | 1600 | Suitable for finishing and semi-finishing of stainless steeland conventional | |||
| alloy steel. | ||||||||
| YW2 | M20 | 13 | 90.6 | 1800 | The grade can be used for the semi-finishing of stainless steel and low- | |||
| alloy steel and it is mainly used for the machining of railway wheel hubs. | ||||||||
| YT15 | P10 | 11.4 | 91.5 | 1600 | Suitable for the finishing and semi-finishing for steel and cast steel with | |||
| a moderate feed rate and rather high cutting speed. | ||||||||
| YT14 | P20 | 11.6 | 90.8 | 1700 | Suitable for the finishing and semi-finishing for steel and cast steel . | |||
| YT5 | P30 | 12.9 | 90.5 | 2200 | Suitable for the heavy duty rough turning of and cast steel with a big feed | |||
| rate at a medium and low speed under unfavorable working conditions. | ||||||||
Why choose us?
1,About our company
Zhuzhou Hongtong Tungsten Carbide Co., Ltd is one of the most professional cemented carbide manufacturers located in Zhuzhou City, the world-renowned cemented carbide hometown. Having been involved in this field for over 14 years, we have rich experience in both production and research of carbide products. Europe, Asia, Africa, and Middle East are our current markets.
2,About our products
Advantages of our carbide products:
1) made from 100% virgin raw material;
2) produced with advanced equipments;
3) all products go through in-process and final inspection;
4) free technical service online.
Categories of our products:
1) Carbide drawing dies;
2) Carbide rods;
3) Carbide strips;
4) Carbide inserts;
5) Carbide disc cutters;
6) Carbide balls/ tire studs/
7) Carbide drilling bits;
8) Carbide Plates,
9) Carbide cold-forging dies;
10) Other customized items.
3,About our service
1) OEM & ODM are welcomed;
2) customized design is available;
3) reply your enquiry in 24 working hours;
4) experienced staffs answer all your questions in fluent English.
