Solid Sintered Carbide Tips

Solid Sintered Carbide Tips thumbnail-1
Solid Sintered Carbide Tips thumbnail-2
Solid Sintered Carbide Tips photo-1
Solid Sintered Carbide Tips photo-2
US$ 58 - 70 MOQ: 5 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
Lipai
Model Number:
YG8,YG6
Contact Supplier Request Quote Chat Now
Zhuzhou Hongtong Tungsten Carbide Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port in china
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hunan, China
Brand Name Lipai
Model Number YG8,YG6
Type Countersink Drill Bit
Material Tungsten Carbide
Use Wood Drilling

Application.
Tungsten carbide brazed tips has the characters of high wear resistance and good compressive properties. They are widely used for cutting wood, metal, or other hard materials, and also used for turning, milling and thread of cast iron or steel. Further more, they're widely used as agricultural machines accessories.



Properties.
--Easy to weld, no crack
--Superior wear resistance
--High hardness and strength
--OEM & ODM are welcomed
--Fast delivery and after-sale service timely



Grades recommend.

Grades

Density

(g/cm³)

Hardness

(HRA)

T·R·S (MPa)

Application Recommended

YG4C

15.00

89.5

1800

Mainly used as small buttons for percussion bits and as the inserts of rotary prospecting bits to cut soft, medium-hard formations.

YG6

15.80

89.5

1700

Mainly used as the buttons of small and medium-sized percussion bits and as the inserts of rotary prospecting bits to cut soft, medium-hard formations.

YG8

14.70

88.5

2300

Mainly used as the buttons of small and medium-sized percussion bits and as the inserts of rotary prospecting bits to cut soft, medium-hard formations.

YG8C

14.70

88.0

2300

Mainly used as the buttons of small and medium-sized percussion bits and as the inserts of rotary prospecting bits to cut soft, medium-hard formations.

YG9C

14.50

87.0

2400

Mainly used as the inserts and buttons for rotary-percussive bits, coal-cutting bits and tricone bits to cut medium-hard and hard formations.

YG11C

14.40

86.5

2450

Chiefly for the inserts and buttons of heavy rock drill bits and rotary-percussive bits, coal-cutting bits and tricone bits to cut medium-hard and hard formations.

YG13C

14.30

86.0

2500

Mainly used as the inserts and buttons of tricone bits rotary-percussive bits and heavy rock drill bits to cut medium-hard and hard formations.

YG15

14.00

86.5

2500

It is stronger, and is mainly used as the inserts and buttons of rotary-percussive bits, heavy rock drill bits to cut hard and very hard formations.

YG16

14.10-14.30

87.5

2400

It is mainly used for making cemented carbide substrate tips to be used in PDC cutters for excavating coal and oil field PDC bits.

YG20

13.40-13.70

85.0

2254

Mainly for the stamping dies used in the conditions of heavy impact load and large strees


Company info.
Zhuzhou Hongtong, a professional Chinese manufacturer of tungsten carbide products. We supply tungsten carbide ball/seat, seal ring,plate,strip,nozzle,rod,brazed tips,mining tips,inserts,disc cutter,wire drawing die,cold heading die,and so on. With more than 10 years experience, we can provide you more than you can image.
