PP Quick Release Full Cone Spray Nozzle

PP quick release full cone spray nozzle

Design features
1.Easy nozzle replacemet

Easy dismantling nozzle design,the nozzle and spray head canbe quickly dismantled you can rotate the spry head by 90 degree to install it or split if from nozzle by hand. so it can significantydowntime durng maintenance.

2.Auto orienting spray head

There is an interior block,whch can keep nozzl in rgh positin wihout manual adjustment.Therefore,it can avoid quality problem caused by wrong orientation of nozzle.

3.Anti-corrosion and wearable

Easy split nozzle: Made of GlassFibe PP(25%),Carbon Fiber PP (40%) and PVDF,featued highintensity,wearability and anicorrosion,Suitable for washing and rinsing of corrosive solution, such as phosphate,acid &solvent: Max temperature for Glass Fiber PP is 82 degree: Max temperature for Carbon Fiber is 120 degree: While PVDF is high pur without pigmen which can keep hg purity in processing,and te max temperture is 148 degree under 7kg pressre.

4.Widely capacity choice

Available sizes:1/8",1/4" and 3/8"

Performance Parameter

Application

1.PCB

2.Wach&Rinse

3.Phosphatization for metal parts

4.Cooling

5.Moistening

6.Chemical Manufacture

7.Dust Removing

Spray pattern:
