Home > Manufacturing & Processing Machinery > Machine Tools > Milling Machine > BTM 600 Bed-Type Milling Machine
BTM 600 Bed-Type Milling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
Used
Place of Origin:
Shandong, China
Brand Name:
Eagle
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Bed Type Vertical Milling MachineNegotiableMOQ: 1 Set -
Universal Vertical And Horizontal Milling MachineNegotiableMOQ: 1 Set
-
UHM 460 & UHM 500A Milling MachineNegotiableMOQ: 1 Set
-
Best Selling Turret Milling Machine 12x54" 12x60"NegotiableMOQ: 1 Set
-
13x54" 13x60" Universal Turret Milling MachineNegotiableMOQ: 1 Set
Condition
Used
Place of Origin
Shandong, China
Brand Name
Eagle
Model Number
BTM 600 Bed-Type Milling Machine
Type
Universal
CNC or Not
Normal
After-sales Service Provided
No overseas service provided
Specifications
BTM 600 Bed-Type Milling MachineBTM 600 Bed-Type Milling Machine
| Swivel head when horizontal milling |
|
Advanced design,largeload and wide machining range |
| Model | Units | BTM 600 |
| Table size | mm | 2500×600 |
| Table travel(x,y,z) | mm | 1500×650×700 |
| Min. distance from hor. spindle axis to worktable surface | mm | 30 |
| Min. distance from vertical spindle nose to worktable surface | mm | 49 |
| Distance from vertical spindle axis to column guideway | mm | 110 |
| Spindle speed range | r/min | 50~1624 |
| Number/Width/Distance of T-slot | mm | 3-22-152 |
| Spindle taper | ISO 50 | |
| Longitudinal, cross feed speed range | mm/min | 20~2200 |
| Rapid feed speed(x,y) | mm/min | 3000 |
| Rapid feed speed(z) | mm/min | 3000 |
| Power of spindle motor | kw | 11 |
| Max. load of worktable | kg | 3000 |
| Overall dimension(L×W×H) | mm | 3200×3200×2720 |
| Net weight | kg | 12000 |
| Item No. | 136130 |
