Universal Vertical And Horizontal Milling Machine

Name: Universal Vertical And Horizontal Milling Machine
Brand: Eagle
SKU: 140924702
Availability: InStock

Eagle Industries, Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

Used

Place of Origin:

Shandong, China

Brand Name:

Eagle

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Condition Used

Place of Origin Shandong, China

Brand Name Eagle

Model Number Universal Vertical And Horizontal Milling Machine

Type Universal

CNC or Not Normal

After-sales Service Provided No overseas service provided

Specifications

Universal Vertical And Horizontal Milling Machine

Standard equipment:	Optional equipment:
Electro cabinet and hung up control panel	X/Y axis inverter motor power feed 0-3500mm/min
Knee rapid elevating motor	X/Y axis gear box power feed
Cooling system	X/Y axis power feed
Electro lubricate pump	Digital readout
Draw bar	Air draw bar (for vertical spindle)
Oil collecting plate	Horizontal milling tools arbor
Working lamp	Inverter vertical milling head
Plastic splashing guard	Variable speed vertical milling head
Leveling wedge and screw

Model		Unit	VHM 30	VHM 30A		VHM 30B
table size		mm	300×1300	300×1300	300×1500	300×1370	300×1500
Table longitudinal travel(manual)		mm	845	845	1000	880	1000
Table cross travel(manual)		mm	385	385	385	380	380
Knee vertical travel(manual)		mm	435
Table longitudinal feed rate		mm/min	0-3500Servo Motor	-	-	-	-
Table cross feed rate		mm/min	0-3500Servo Motor	-	-	-	-
Knee rapid speed		mm/min	900
Vertical Spindle	Motor power	HP	5HP			Standard: 3HP/optional: 5HP
	Speed	rpm	(Standard: 16 steps ) : 50HZ: 65-4500 60HZ: 80-5440 (optional: variable speed): 65~3750
	Taper		ISO40			Standard: R8 / optional: ISO40
	Quill travel	mm	127
	Quill feed	mm/rev	0.04 /0.08 /0.15
	Head rotating		(R/L) 90°			(R/L) 90°/(B/F)45°
	Distance from spindle end to table surface	mm	115~545
Horizontal Spindle	Motor power	HP	5HP
	Speed	rpm	50HZ: 45/80/165/260/500/980 60HZ: 55/100/200/315/600/1180
	Taper		ISO40
	Distance from spindle center to table surface	mm	-20~410
	Distance from spindle center to ram	mm	183
Ram travel		mm	480
Ram rotating			360°
Net weigh		Kg	1900	1900	1950	1680	1730
Package size L×W×H		cm	180×150×220	180×150×220	180×180×220	180×160×220	180×180×220
Item NO.			132010	132020	13021	132030	132031
