Accu-lock Milling Machine Vise

FOB Price

Negotiable / Set

10 Sets(Min. Order)

Port Qingdao
Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	Eagle
Model Number	PL100

Product Description

Specifications

1. Accu-lock Milling Machine Vise
2. High quality

Accu-lock Milling Machine Vise

Model	Jaw width	Jaw height	Max opening	Overall Height	Weight (lbs)	Item No.
PL100	4"	1-1/8"	4"	3-3/8"	46	541043
PL125	5"	1-5/6"	4-1/4"	3-13/16"	70	541045
PL160	6"	1-1/2"	5-1/4"	5-3/8"	100	541047
PL200	8"	2"	7-1/2"	5-5/6"	225	541049
6" Vise with 7-1/2" Jaw Opening W/O swivel base
PL161-1	6"	1-1/2"	7-1/2"	4-3/8"	105	541051

Accu-lock precision machine vises

Performance and characterist:
1.It is main attchments to precision millings grinders CNCmachines it is particularly suitable for the finishing of precision parts.

2.Parallelism 0.025mm/100mm,squareness 0.025mm

3.The special segment in the movable jaw forcess the vertical pressure downward when the horizontal pressure works,so that this jaw does not lift the workpiece.

4.For positions allow extra capacity to change opening of jaw.

5.As the thrust component of the screw is equipped with thrust needle bearing if can be easily operated.

Model

Width of jaw (mm)

Hight of jaw (mm)

Max. opening (mm)

GW./ NW. (kg)

packing volume L×W×H (mm)

Pzcking shape

Item NO.

QM16160N

160

140

36/35

48×20×21

wooden case

541010
