second Tannery machine key word
1.small size toggling
2.lower temp finalize the design
3.steam,natural gas as recycling hot energy
4.toggling dry the carton
Technical parameters of second Tannery machine
No | Part | Detail |
1 | Working area | 2m to 1m |
2 | Toggling number | 20 |
3 | Number for leather for stretch once time | 1000 pcs |
4 | Max temp of oven | 60 degree |
5 | Steam pressure | 0.4-0.6mpa |
6 | Steam consumption | 30L/h |
7 | Air pressure | 4-6h |
8 | Drying time | 0-150mm |
9 | Range for stretch | Max more 4 person |
10 | Operate worker | 11kw |
Material of second Tannery machine
No | Machine part | Description |
1 | Machinery structure | Square pipe weld for dry room, square pipe size:50x50x2, 50x30x2mm |
|
| Steel with foam for outside structure , 50mm thickness |
2 | Toggling structure | Seamless tube n60x4mm, steel pipe n48x4mm,square pipe 40x40x3.5mm, Weld together for toggling |
3 | Toggling screen | Steel 1.8mm punching into screen |
4 | Guide system | Each toggling distance is 160mm,guide steel :80x8mm,pulley make the guide system |
5 | Guide crossbirdge | Weld by 50x30x2.5mm square pipe,10# and 12# u-steel with 50x30x2.5mm square pipe,5#angle iron,8mm A3 steel make up |
6 | Dry system | The steam as heat source,bolwer (0.75kw,diameter 500mm fan blade),radiator make the dry device.
|
7. | energy | steam ,gas,electric ,hot oil |
second Tannery machine leather type
crocodile,Steer hide,cow,crown,dog skin,saffian,sheep,Wool skin,Cow hide,Calf skin,Kangaroo,Kid skin
Kip skin,Cattle hide,Glace kid,Deer skin,Water buffalo hide,chamois
second Tannery machine buyer
France ,Indonesia ,Pakistan , India ,Mongolia ,Malaysia and so on
second Tannery machine Spare parts supply
Item | Name | Q’ty |
1 | All air parts | 1 set |
2 | Electric valve | 1 set |
3 | Limited switch | 2pcs |
4 | Travel switch | 2pcs |
5 | Motor | 2 pcs |
6 | contactor | 2pcs |
7 | Operate Tool | 1 Set |
