20m goat sheep skin Automatic Toggling machine
- Shanghai port
- T/T Credit Card
You May Like
-
20m length 2.2m width leather Automatic stretching dry machine
-
tannery machine leather Italy quality china price 20m Automatic stretching dry machine
-
China tensile stretching test machine for leather
-
continuous automatic leather toggling machine
-
Crocodile dog skin sheep Kangaroo Leather Toggling drying machine
-
leather dewatering machine
Product Details
| Condition | New | Automatic Grade | Automatic | |
| Place of Origin | Jiangsu, China | Brand Name | DUNCHENG | |
| Model Number | DCH | Type | Other, Automatic Toggling machine | |
| Voltage | 380v/3phase | Power(W) | by the size | |
| Dimension(L*W*H) | by the size | Weight | by the size | |
| Certification | ce | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Automatic Toggling machine1.chain slat driver type
2.low consume
3.auto count and finalize the design
4.toggling machine
Automatic Toggling machine key point
1.PLC control
2.continues running
3.two radiator
4.galvanize steel
5.dry energy : steam,electric,hot oil , natural gas and so on
6.for sheep goat cow and so on
Automatic Toggling machine Specification
Auto toggling machine information | ||||||||
Model | Work size (m) | Stretching size (mm) | Capacity (PCS) | heat producer (Mpa) | Dryer temperature (degree) | Speed (m/min) | Power (kw) | Weight (Kg) |
DCH3-160 | 1.6 | 0-120 | 60-220 | 0.3 steam | 20-70 | 16.5 | 12.55 | 12970 |
DCH3-180 | 1.8 | 13.55 | 13500 | |||||
DCH3-200 | 2.0 | 14.55 | 14000 | |||||
DCH3-220 | 2.2 | 14.55 | 14700 | |||||
Automatic Toggling machine buyer
France ,Indonesia ,Pakistan , India ,Mongolia ,Malaysia and so on
Spare parts supply
Item | Name | Q’ty | Code in circuit diagram | remark |
1 | Sheet of chain | 30 pcs |
|
|
2 | PLC | 1PC |
|
|
3 | Text display | 1pc |
|
|
4 | Small relay | 4pcs | KOO |
|
5 | fuse | 2pcs | Q |
|
6 | contactor | 2pcs | KO |
|
7 | Temperature meter | 2pcs | SWK |
