Specifications
Vibration staking machine supplier1.auto remove crease
2.auto air dusty collect
3.auto lubration system
vibration staking machine supplier key point
1.Auto lubricating system
2. Auto remove crease unit
3. Auto air dusty collector
4. PLC control all system
vibration staking machine supplier Specification
Size and head | Work width | Vibration frequency | Feeding speed | Total power | Working pressure | Machine size | Weight |
1600-4 head | 1600mm | 600t/m | 0-20m/min | 22kw | 3.5-4.5mpa | 2220x2970x1610 | 11000kg |
2400-4 head | 2400mm | 600t/m | 0-20m/min | 29.7kw | 4.5-5.5mpa | 3020x2970x1610 | 15000kg |
3200-4 head | 3200mm | 600t/m | 0-20m/min | 29.7kw | 4.5-5.5mpa | 3820x2970x1610 | 18000kg |
Size and head | Work width | Vibration frequency | Feeding speed | Total power | Working pressure | Machine size | Weight |
1600-3 head | 1600mm | 600t/m | 0-20m/min | 23.4kw | 3.5-4.5mpa | 2220x2970x1610 | 9000kg |
2400-3 head | 2400mm | 600t/m | 0-20m/min | 30.4kw | 4.5-5.5mpa | 3020x2970x1610 | 11000kg |
3200-3 head | 3200mm | 600t/m | 0-20m/min | 38.4kw | 4.5-5.5mpa | 3820x2970x1610 | 14000kg |
Size and head | Work width | Vibration frequency | Feeding speed | Total power | Working pressure | Machine size | Weight |
1600-2 head | 1600mm | 600t/m | 0-20m/min | 9kw | 3.5-4.5mpa | 2220x2970x1610 | 6500kg |
2400-2 head | 2400mm | 600t/m | 0-20m/min | 12.5kw | 4.5-5.5mpa | 3020x2970x1610 | 7500kg |
3200-2 head | 3200mm | 600t/m | 0-20m/min | 17.2kw | 4.5-5.5mpa | 3820x2970x1610 | 9000kg |
vibration staking machine supplier part brand
No | Part | Brand list |
1 | BEARING | JAPAN |
2 | Hydraulic pump | JAPAN |
3 | Breaker | JAPAN OR FRANCE |
4 | Contactors | JAPAN OR FRANCE |
thermal relay | JAPAN OR FRANCE | |
air base | GERMANY | |
cloth | ITALY | |
valve | JAPAN |
