Roller Leather Ironing Machine

Specifications

roller leather ironing machine

1.700mm ironing(embossing ) roller surrounded by three small rollers

The largest structure characteristics is the 700mm ironing(embossing) roller surrounded by three small rollers to form a complete leather heating and pressing space, the three pressure rollers can adopt pneumatic pressure with 0-6kg/cm2 and the front and behind pressure roller can adopt hydraulic pressure with 0-150kg/cm2 ,the effect is better than the machine with one roller or embossing roller

2.the machine can produce the perfect leather

The unique structure of machine can produce the perfect leather , the three pressure rollers can adopt one-point ,two-point or different combinations to pressurize, the machine can be applied to all kinds of leather surface characteristics and requirements ,such as bag leather and clothing leather with lower temperature and lower pressure to press ,it appear natural and smooth leather surface pores and there are no loose surface and leather surface brightness deviation ,however, the shoe upper leather with high temperature and different combinations to press it can make leather shining and no glare.

3.one machine for different use

The machine is used for embossing ,the lower part has more perfect ironing function than traditional ironing machine ,the new machine can be used for ironing and embossing by sand roller ,the super mirror surface of ironing roller can make the surface of leather shinning and improve the quality

4.leather to produce perfect natural luster

The sand roller can make natural shining effect on the leather without diffused reflection, covering small defects ,fro example small wrinkles ,scratches and phenol marks

5. working in lower temperature ,lower pressure without leather surface brightness deviation

Working in lower temperature, lower pressure, without leather surface brightness deviation, the machine can ensure product uniformity ,especially in processing of senior leather with higher performance guarantee

6.cycle oil to heat the ironing(embossing ) roller

Automatic display, automatic temperature control, the highest temperature is 190 degree, a spare roller preheating device,, the spare roller can be heated before change ,fast heating and there is no temperature influence to the working roller ,we can save time

7.three different functions of delivering leather belt ,leather is not easy to fold

Three different functions of delivering leather belt and pneumatic automatic adjusting, deviation adjusting function is sensitive and reliable ,make the leather after stretching tin to the ironing zone ,fur is not easy to wrinkle ,improve the yield of leather

8.frequency conversion stepless speed regulation

Each conveyor belt adopt frequency conversion stepless pseed regulation and have inverter heat radiating device , automatically display the speed of conveyor belt ,a clear reflection of the speed difference ,conducive to the realization of leather wrinkle free press

9.machine performance is stable and reliable

The machine adopt high intensity ironing(embossing ) roller and a pressure roller and a rigid frame ,and the import hydraulic pump ,oil pump and rotary joints and so on ,change ht roller by the hoist quickly and smoothly, machine performance is stable are reliable ,reasonable layout beautiful and have improved the safety operation guarantee system ,safe operation .

roller leather ironing machine Machine detail

roller leather ironing machine Machinery function

roller leather ironing machine Spare part free

payment: 30% deposit TT,balance money paid off before shipment.

delivery time : 60work days after get 30% deposit(some time with in store)

packing :plastic wrap and cover

warrantee time :one year
