Specifications
Continuous through feed press for sale1.embossing ,shining roller
2.through feed pressure
3.hydraulic pressure
Model | DCH | 1600 | 2100 | 3000 | 3200 |
Working width | Mm | 1600 | 2100 | 3000 | 3200 |
Working pressure | Kg/cm | 240 | 240 | 200 | 240 |
Power(3 roller) | Kw | 87 | 102 | 120 | 135 |
Power(1 roller) | kw | 25 | 30 | 35 | 40 |
Working temperature | Degree | 180 | 180 | 280 | 180 |
Working speed | m/min | 3/17 | 3/17 | 3/17 | 3/17 |
Weight (auto) | Kg | 14000 | 15500 | 17300 | 18800 |
Weight (crane) | kg | 11900 | 10900 | 12300 | 12600 |
Weight of one roller | Kg | 1100 | 1300 | 2000 | 2100 |
Overall dimensions | mm | 4100x2200x2400 | 4600x2200x2400 | 5500x2200x2400 | 5700x2200x2400 |
1.super solid frame. No deformation: using he special steel which has taken the heat treatment and stress treatment ,this machine can keep its sharp under the high pressure
2.using super heavy roller to ensure the embossing effect: the diameter of pressure roller is 500mm ,and the diameter of pressure roller is 700mm , we also using special material to ensure the quality of embossing work
3.automatic roller change device: on one shaft, 3 roller are installed (two for embossing ,one for iron),by using the reducer ,rollers can be shifted automatically ,this techniology is unique in the china
4.multiple rollers independent heating system ,each roller has its own heating system , by pushing the bottom ,the working roller can be shifted to the work position to heat , no extra heating is required
6.the heat uniformity or distribution systems by computer control: the system of heat oil inside, control by computer distribution technology keep the temperature of roll face uniformity
7.special techniques,ressure regulating device:10 pressure ironed up to 150kg pressure of the ironing ,the most important is the pressure from 10 to 150 kg pressure process can he fine –tuning ,this technology is the first in the country
8.the device of unique leather stretch contribute :even a think sheep leather ensure the stretching process does to fold ,improve the leather rate
9.automatic hydraulic felt adjusting system ,ensure felt in central position
