1370x1000mm Cow Crust Hydraulic Leather Flat Embossing Machine
- CHINA
- T/T Credit Card
You May Like
Product Details
| Condition | New | Automatic Grade | Automatic | |
| Place of Origin | Jiangsu, China | Brand Name | DUNCHENG | |
| Model Number | DCH | Type | Embossing Machine | |
| Voltage | 380v/3phase | Power(W) | up to machine | |
| Dimension(L*W*H) | up to machine | Weight | up to machine | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
hydraulic leather plate embossing machine1.hydraulic embossing machine
2.300t,600t,850t,1100t,1500t
3.two plates free
hydraulic leather plate embossing machine key point
1.plate hydraulic embossing machine
2.300t 600t 850t 1100t 1500t pressure
3.snake ,crocodile ,cow, sheep ,goat and so on
4.cooling system: water, steam
hydraulic leather plate embossing machine Specification
Total power(T) | 300 | 600 | 700 | 850 | 1100 | 1500 |
Std. size of plate(mm) | 915×560 (915×720) | 1370×915 (1370×1000) | 1370×915 (1370×1000) | 1370×915 (1370×1000) | 1370×915 (1370×1000) | 1370×915 (1370×1000) |
Hydraulic pressure circuit (kgf/cm2) | 250 | 250 | 250 | 250 | 250 | 250 |
Space between tables(mm) | 110 | 130 | 130 | 130 | 160 | 140 |
Frequency of stroke(str/min) | 8-10 | 8-10 | 8-10 | 8-10 | 8-10 | 8-10 |
Motor power(Kw) | 7.5 | 7.5 | 15 | 18.5 | 30 | 37 |
Heating way | Electric | Electric | Electric | Electric | Electric | Electric |
Electric heater power(Kw) | 9 | 18 | 18 | 18 | 18 | 18 |
Overall dimensions(L×W×H)(cm) | 100x180x205 | 170x230x260 | 170x250x260 | 170x280x270 | 170x340x310 | 170x350x310 |
Weight(T) | 3.8 | 12.5 | 15 | 17 | 24 | 32 |
