Specifications
fleshing machine1.Italy technical
2.for any thickness
3.best quality
4.special for cow
fleshing machine key point
1.hydraulic system fleshing machine
2.stainless steel machinery structure
3.special for cow cattle buffalo and so on
4.one system for control two sets machine running together
5.auto balance unit Rubber rod pallet for keep difference thickness skin get good finally quality
6. rhombic channel roller ensure skin never move during running
7.double times auto protect system
8.auto grinder for blade
fleshing machine Specification :
Working width (mm) | 2200 | 2700 | 3200 |
O/D of blade cylinder | 260 | 260 | 260 |
Speed of blade cylinder | 1480 | 1480 | 1480 |
Main motor (KW) | 45 | 45 | 55 |
Pump pressure (bar) | 40-45 | 40-45 | 40-45 |
Feed speed (m/min) | 19-50 | 19-50 | 19-50 |
Oil pump motor (Kw) | 11 | 11 | 15 |
Capacity(pc/h) | 120-150 | 120-150 | 120-150 |
Outline (LxWxH) (mm) | 4400x1540x1600 | 4900x1540x1600 | 5400x1540x1600 |
Net weight (KG) | 7200 | 7850 | 9000 |
fleshing machine warrantee time :
one year after machinery arrive in buyer factory ,during one year ,if machinery part damage except by person, factory free change ,but transport charge paid by buyer
ORDER GUIDER:
