Help Center400A Electroplating Rectifier
Related Products
-
200A 24v High Frequency Portable Power SourceNegotiableMOQ: 1 Unit -
CE Approved IGBT Chrome Plating Rectifier 12vNegotiableMOQ: 1 Unit
-
Customized Available Nickel Plating RectifierNegotiableMOQ: 1 Unit
-
High Switching Precision Intelligent Electroplating MachineNegotiableMOQ: 1 Piece
-
Ac to dc Double Adjustable Power Supply for PlatingNegotiableMOQ: 1 Unit
electroplating:
Features & Specification of Basic Model
type |
DR-500A-12V |
|
|
Electrical specification |
Input voltage |
single phase AC220±15% 50HZ |
Rated output voltage |
0-12V |
|
Rated out current |
0-500A |
|
Rated out power |
|
|
|
Range of output Conditioning |
At 0 to100% of rated voltages |
|
At 0 to100% of rated currents | ||
Adjustment range |
From 0-100%continuously adjustable |
|
Output conditioning method |
Switching mode |
|
Machine efficiency |
≥90% |
|
Constant voltage control accuracy |
Within 1.0%of rated output voltage |
|
Constant current control accuracy |
Within 1.0%of rated output current |
|
Insulation resistance |
5MΩor more |
|
Cooling system |
Forced air cooling |
|
|
Working condition |
Location |
Indoors |
Ambient temperature |
-20-55°C(overheating self-protect) |
|
Relative humidity |
30-85% |
|
1. small,light and efficient.
The proper combination of unique assembly structure and nanotechnology makes it small in size and lightweight ,saving space and improving efficiency.
2.. high-frequency pulse current output.
It can be used in the electroplating of non-ferrous metals and alloys ,With strong penetrability and adhesion.it can significantly quicken deposition rate of the plating coat.
3.easy and flexible operation.
The output voltage and current can be adjusted freely and flexible according to the electroplating requirements. It can also be flexible switched between constant voltage and constant current.
4. complete protection funcrtions.
5. It has many functions which protect against input under-voltage,over-voltage ,phase loss, output over-current and overheating respectively.
The duct treated internal structure enables reliable performances of the whole product .All of the electronic elements are sealed completely to reduce harm from the exterior environment and ensure stable and long-term operation .
6. Expandable functions .Timing control function and communication function .(4-20mA,0-5V and 0-10v standard control signal interfaces are optional)
Soft start and current calculation (ampere hour)
7. Complete models .Optional output specifications (output voltage and current ) .Optional matching functions and control modes.
Applications :it can be used in electroplating of acid copper ,alkali copper,nickel, zinc and chrome ,as well a electrolytic degreasing.(code01-5)
