Good Quality JT Series Monocular Hoist Winch /Drawworks machine manufacturer in China
Product Introduction
JTseries Monocular and Binocular Hoist Winch adapts 5 grade resistance manual control speed regulation ,stable startup,metting withi requirments of coal mine regulation ,mounting some safety production devices like depth indicator over windingproof device ,hydraulic break ,hand break ,etc.Both Monocular and Binocular Hoist Winches are integral hoisting ,which have the characteristics such as time saving and power saving ,compact conctructure ,convient transportation,easy to operate.etc.It is mainly applicable to dominicable to dominical and accessory drawing ,drawing up and down hills,it is the ideal drawing machine for the mine.
Technical parameters:
Model |
| JT-0.6*0.55 | JT-0.6*0.55 | JT-0.8*0.6 | JT-0.8*0.6 | JT-0.8*0.6 | JT-0.8*0.95 | 2JT-0.8*0.46 |
Hoisting capacity(N) |
| 12000 | 14700 | 11760 | 15000 | 14700 | 14700 | 11760 |
rope capacity (m) |
| 210(3 layers) | 210(3 layers) | 280(3layers) | 280(3layers) | 280(3layers) | 474(3layers) | 240(3layers) |
Average speed(m/s) |
| 0.95 | 0.95 | 1.4 | 1.06 | 1.4 | 1.4 | 1.4 |
Diameter of steel wire(mm) |
| 15.5 | 15.5 | 15.5 | 15.5 | 15.5 | 15.5 | 15.5 |
Roller quantity(PC) |
| 1 | 1 | 1 | 1 | 1 | 1 | 2 |
Diameter of roller(mm) |
| 600 | 600 | 800 | 800 | 800 | 800 | 800 |
Width of roller(mm) |
| 500 | 600 | 600 | 600 | 600 | 950 | 460 |
Transmission ratio |
| 33.075 | 30 | 30 | 30 | 30 | 30 | 30 |
Rating electro motor | Model | YR180L-6 | YR200L-6 | YR200L-6 | YJZR51-8 | YR225M1-6 | YR225M1-6 | YR200L-6 |
| Power(kw) | 15 | 18.5 | 22 | 22 | 30 | 30 | 22 |
| Revolving speed(r/min) | 947 | 947 | 955 | 730 | 955 | 955 | 955 |
| Voltage(v) | 380 | 380 | 380 | 380 | 380 | 380 | 380 |
ood quality&favorable price
We can offer you competitive price with good quality
e can offer you competitive price with good quality
We strictly control every process in production to provide
top quality products for our customers.
3.Professional group
We have a professional foreign trade team for auto parts export,
so we can provide you with professional services!
4.Quality warranty:
One Year Warranty
We try our best to make sure our customers enjoy good after-sales service.
The Information you may like to know before order:
1. Payment:
T/T (Telegraphic Transfer) or L/C at sight
2. Delivery
Based on order quantity, normally it takes 5-10 days for production.
3. Shipping way
Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air
Bulk order: we suggest by air or by sea.
4. Quality Control
We have our own experienced QC.
There will be strict inspection and testing for every order before shipping out.
5. After Services
1. Our sales team will response for your question within 24 hours (Holidays Excluded)
2. Technical Support will be available in any time
3. Free replacement will provide once the failure confirmed caused by our product quality
JINING BAFANG MINING MACHINERY CO., LTD
is specialized in manufacturing mining machinery in China.
We are committed to researching and developing
all kinds of mining and stone processing equipment.
Our main products include rock drills,
guniting equipment s , pumps, mining support equipment s ,
mine car hardware tools, electrical equipment s,
fasteners and other related accessories .
Our products have been exported to more than 20 countries and regions,
such as Brazil, Russia, Australia, Africa, South America
and Middle East with our outstanding quality,
competitive price and on-time considerate service.
We have won a high reputation from our esteemed customers .
We warmly welcome old and new customers from all over the
world to visit our company and establish business
relationships with us.
We do believe that our mutual cooperation will create a brilliant
future.
If you have any need,please let me know.
e can offer you competitive price with good qualityQuality checkin
