AE102 medical oxygen concentrator pump

Specifications

oxygen filling pump
1.Max exhaust pressure: 30MPa
2.Exhaust Capacity while pumping: 3L/Min
3.Grade of compress:

Specifications
oxygen filling pump
1.Max exhaust pressure: 30MPa
2.Exhaust Capacity while pumping: 3L/Min
3.Grade of compress: 2
oxygen filling pump
It is an oxygen filling equipment that step up oxygen pressure from source bottle to another gas bottle.
AE102 Oxygen-Filling Pump is an oxygen filling equipment that step up oxygen pressure from source bottle to another gas bottle, let the oxygen pressure of this gas bottle achieve the needed pressure

Main specification other gas bottle, let the oxygen pressure of this gas bottle achieve
Item	Specification
Max exhaust pressure	30MPa
Exhaust Capacity while pumping	3L/min
Grade of compress	Grade 2
Max compress rate	8
Revolution of crankshaft	440rmp
Plunger stroke	30mm
Plunger diameter	Grade one ,18mm	Grade two,12mm
Power of motor	2.2kw
Rotate speed	1410r/min
Voltage of motor	380V/50Hz
Dimensions	860X565×640mm
Weight	116kg
