Specifications
Metal plate beveling machine1. Low energy consumption & quick beveling
2. Three times of flame cutting
3. No cleaning bur
This Milling and Beveling Machine applies the roll-beveling principle to cut the steel plate edge side according to the given angle, so that it can get the bevel for the welding. The beveling size is correct, the beveling surface is smooth, also can get the shape for one time, no need to clean the burr, which has the good character as easy operation, high efficiency (3m per minute) and lower consume, and the other excellence.
1. The beveling machine is adopted with the milling principle to mill the angle for the edge of the steel plate, and to get the groove for welding.
2. The machine is accurate in size, bright and smooth in surface, and is formed once.
3. There is no need of de-burring.
4. convenient in operation, very high in working efficiency (three meters per minute) and low in energy consumption.
It is an ideal angle machine for beveling of Q235 carbon steel plates,16Mn (low alloy steel plates) and stainless steel plates.
Specification
Strength of plates (N/min-1) |
<400 |
>400~500 |
>500~600 |
Steel plates |
Q235 |
16Mn |
Stainless steel |
Max. width of beveling (mm) |
20 |
16 |
12 |
Feeding speed (m/min) |
2.9 |
3.1 |
3.4 |
Max. thickness of plate (mm) |
45 |
||
Scope of beveling angle (º) |
25~45 |
||
Min. residual (mm) |
2 |
||
Power of motor (kw) |
4 |
||
Speed of spindle (r/min) |
7.7 |
||
Diameter of hob (mm) |
200 |
||
Voltage V |
380V 3-phase power supply 50Hz in China (May custom-made) |
||
Size mm |
1240*900*1500 mm |
||
T/T (Telegraphic Transfer) or Western Union or L/C at sight
2.Delivery:
Based on order quantity, normally it takes 7-20 days for production.
3.Shipping
Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air
Bulk order: we suggest by air or by sea.
4.Quality Control
We have our own experienced QC.
There will be strict inspection and testing for every order before shipping out.
5.After Services:
1. Our sales team will response for your question within 24 hours (Holidays Excluded)
2. Technical Support will be available in any time
3. Free replacement will provide once the failure confirmed caused by our product quality
